Home > Lights & Lighting > LED Lighting Decoration > LED Strip Light > High CRI >80/90 500mm 1000mm Length LED Liner Light / Led Aluminum Profile

High CRI >80/90 500mm 1000mm Length LED Liner Light / Led Aluminum Profile

High CRI >80/90 500mm 1000mm Length LED Liner Light / Led Aluminum Profile thumbnail-1
High CRI >80/90 500mm 1000mm Length LED Liner Light / Led Aluminum Profile photo-1
US$ 3.6 - 8 MOQ: 50 Pieces
Key Specifications
Get Latest Price
LED Light Source:
SMD
Type:
LED Bar Lights
Input Voltage(V):
DC24V
Contact Supplier Request Quote Chat Now
Shenzhen Starwire Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD
Type LED Bar Lights
Input Voltage(V) DC24V
Lamp Power 14
Lamp Luminous Flux(lm) 1250lm
Color Temperature(CCT) WW/NW/CW
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 35000
Lamp Body Material Aluminum
Certification CE, EMC, LVD
Emitting Color White
Place of Origin Guangdong, China
Brand Name SW
Model Number SW-1707

Starwire LED Linear / LED Light Bar...



 1. Aluminum profile -- More than 20 type for choices;



2. LED Strip Light -- More than 20 type for choices;



3. Any length & Any brightness can be provided - easy to cuttable;



4. Manufacture supply led strip, led aluminum profile, led controller, DMX, Connector, Driver ...



High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile



Product Description



Specification of led light bar:



Item No. Dimension(mm) LED Power Wattage Ra IP rate Lumen Color
SW-1707 500x17x7mm

SMD2835 60leds

 7W



DC24V



>80/90



IP40
 		625lm







WW:2800-3000K

NW: 4000-4500K

CW: 5500-6500K
1000x17x7mm SMD2835 120leds 14W 1250lm


SW-1612

 500x16x12mm

SMD2835 91leds

 7W 625lm
1000x16x12mm SMD2835 182leds 14W 1250lm




SW-A1919 L500*W19*H19mm

SMD5630 36leds

 8W 750-920lm
L1000*W19*H19mm

SMD5630 72leds

 16W 1500-1840lm



High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile   High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile  High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile

Advantage of Starwire led linear light



1. Designed for flexible led strips.



2. Aluminum profile can dissipate heat much better.



3. High quality aluminum profile makes flex strip more elegant.



4. Provided two types of PC cover: Transparent cover & diffused cover.



5. "T" Shape:  Can be recessed mounted with high lumens transparent pc cover

    "U" Shape: Can be both recessed and surface mounted.

    "V" Shape: Can be corner lighting.

High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profileHigh CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile

High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile





Our Services



1. A whole set includes: 1 PC cover+ 1 extrusion aluminum base+ 2 end caps+ 1/2 clips

2. Aluminum profile
    Surface: anodized silver (Color is changeable per customer's demand)

3. PC cover: diffuser/ opal/ transparent

4. Light source: 3528, 5050, 5630, 5730, 2835

5. Available lengths: 0.5m-3.0m ( Per customer's request)

6. Application: bathroom, refrigerator, ground lighting.

7. Assembly: Screw mounting, chain installation, clip-on installation and inline mounting.



High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile





LED Linear Light Application:



High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile

  High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile







Company Information

 High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile



 High CRI >80/90 500mm 1000mm Length LED Liner Light / led aluminum profile
