Help Center2015 TKFM Water Pipeline Use Flange Connection Dn150 Electric Gate Valve A216 Wcb
Related Products
-
2015 TKFM Factory Directly Sale Flange Connection Dn65 Gate Valve Steam NptUS$ 32 - 1,846MOQ: 10 Sets -
2015 TKFM Flange Connection Wcb 2" Inch Gate Valve PictureUS$ 32 - 1,846MOQ: 10 Sets
-
2015 TKFM Water Medium Flange Connection 4 Inch Ductile Iron Gate Valve With DrainUS$ 32 - 1,846MOQ: 10 Sets
-
2015 TKFM Flange Connection 2 Inch Soft Sealing Gate ValveUS$ 32 - 1,846MOQ: 10 Sets
-
2015 TKFM Hot Sale Big Size Electric Actuator 12 Inch Din Cast Steel Gate ValveUS$ 32 - 1,846MOQ: 10 Sets
Materials of Main Parts
No. |
Name |
Material |
1 |
Valve body |
Ductile Cast Iron |
2 |
Wedge disc |
Ductile Cast Iron with EPDM or NBR rubber coverage |
3 |
Hexagon socket-head cap screws |
Carbonization |
4 |
Sealing ring |
NBR rubber |
5 |
Bonnet |
Ductile Cast Iron Cast Steel |
6 |
Stem |
Stainless Steel |
7 |
O-ring |
NBR rubber |
8 |
Thrust Bearing |
Tin-bronze |
9 |
Bolt |
Stainless Steel |
10 |
Gland |
Ductile Cast Iron Cast Steel |
11 |
Dust cover |
NBR rubber |
12 |
Hand wheel |
Cast Iron |
Main shape connection dimensions
DN |
50 |
65 |
80 |
100 |
125 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
600 |
L |
178 |
190 |
203 |
229 |
254 |
267 |
292 |
330 |
356 |
381 |
406 |
432 |
457 |
508 |
Ha |
313 |
332 |
372 |
424 |
497 |
562 |
680 |
837 |
948 |
1010 |
1220 |
1280 |
1480 |
1665 |
Hc |
355 |
375 |
415 |
476 |
540 |
600 |
720 |
875 |
990 |
1050 |
1245 |
1310 |
1560 |
1750 |
By using rubber coating for the whole gate to produce deformation compensation to achieve good sealing effect. Overcomed other gate valves’ shortcomings such as poorly sealed, leakage or rust. Our gate valve is more effective and save installation space. Widely used in city water supply, sewage treatment, construction industry, petroleum pipe line, chemical industry, foodstuff industry, pharmaceutical industry, textile-industry, power sector, shipbuilding, metallurgical industry, energy system and other fluid pipes as regulator or cut-off equipment.
Technical Parameters
Nominal pressure:1.0~2.5MPa
DN: 50~600mm
Operating temperature :0~80℃
Applicable medium: water oil gas and so on
Flange standard:GB/T 17241.6 GB/T 9113
Test standard: GB/T 13927 API 598
Terms of payment: 30% in advance as deposit, the balance paid before delivery.
Delivery time: 30 days after receiving the prepayment.
Terms of trading: FOB, CFR, CIF
Guarantee: 12 months
Fully welded ball valve - Company advantages:
1. We are factory: Our factory address is: 19-11 Hunnan East Road,Hunnan New district, Shenyang City,Liaoning Province, China. Postcode: 110169
2. Regional Sales: We provide specialized sales service refers to different kind of region all over the world. Each sales team member is good at the local language and well experienced to the responsible market. For example: Russian, German, Spanish, Japanese, etc.
3. Low MOQ: Our factory owns the casting company by itself. We are always ready for providing the sample and producing some small orders, in order to meet the business well.
4. OEM Accepted: We can make the products with the client's demand standard or the custom requirement.
5. Complete Service: We are always ready to hear from you, be responding to your enquiry immediately. Our trade manager is always online for you.
6. Good Quality: We have strict quality control system and amounts of testing equipments for different kind of valve, such as size, pressure, working environment etc. We are winning the market reputation with the time goes by.
7. Quick Delivery: We have the large stock for some hot products.
8. Competitive Prices: We are the manufacturing company which not only has our own manufacturing workshop, but the casting company as well. We provide the straight factory price and service to our customer.
