POE Power Adapter Desktop ac dc 96W 52V
- Shekou Port Yantian Port
- Money Gram Credit Card
You May Like
-
POE Power Adapter ac dc 65W 52V
-
5V 40A 200W Switching Mode Power Supply With 100% Full Load Aging Test
-
Wholesale 12v 1a Power Adapter With CE FCC
-
Security ac Desktop Power Adapter 12V 2A for CCTV Camera
-
High Quality 12V 1.5A 18W 120-240(US) Power Supply Adapter
-
High Quality 12v 1.5A Desktop Power Adapter Double Cable With CE FCC
Product Details
| Place of Origin | Guangdong, China | Brand Name | SX | |
| Model Number | SX100A-SPS-E1 | Output Power | Other, 51 - 100W, 96 | |
| Output Type | Other, Single, single | Input Voltage | Other, 220V, 100V-240VAC Max:90-264VAC | |
| Output Voltage | 5V, 52V | Output Frequency | 50/60Hz, 47~63Hz | |
| Output Current | 0-1.85A, 0-1.85A |
Product Description
Specifications
♦ POE adapter CE FCC ROHS
♦ LED indicator for power on
♦ Low cost ,high reliability
♦ 3years warranty
POE power adapter desktop ac dc 96W 52V
96eries power supply | |
Model: SX100A-SPS-E1 | |
Input Characteristic | |
Input Voltage | 100V-240VAC Max:90-264VAC 47/63Hz |
Input Frequency | 50-60HZ |
Input Frequency Range | 47Hz- 63Hz |
Input Efficiency | >89% |
Input AC Plug |
|
Output Characteristic | |
Output Voltage | 52V ±5% |
Total Output Power | 96.2W |
Output Current | 0-1.85A |
Output ripple /Noise(MV) | <100MV |
HI-Pot test | 3000VAC 10mA(max) |
Insulation Resistance | 500Vdc/20MΩMin/1S |
Mechanical Characteristics | |
Dimension | 140*60*37mm |
AC type | desk-top type, 3 pin |
Case material | PPO,PC, PC+ABS, or equivalent |
Connector DC | 5.5*2.5*10mm |
Drop Test | Drop each side from 1M height to the hardwood which at least 13mm thick,total 6 times. |
Environment | |
Storage Temperature Range | -20 to +60℃ |
Operating Temperature Range | -20 to +40℃ |
Storage RH Range | 5 to 95% |
Operating RH Range | 20 to 90% |
Burn-in | 48 hours |
M.T.B.F(hrs) | 20000 |
Others | |
Protection | Over Current Protection |
Over-load Protection | |
Short Circuit Protection | |
Application | IP Telephones, Wireless Network Access Points,Wireless communication electronics , Blue Tooth Access Point , IP Print Servers, Security Camera,Poe switch |
Packing list | 360*350*275mm 42pcs/carton 290g |
OEM&ODM | Yes |
Product pictures
Application
IP Telephones, Wireless Network Access Points,Wireless communication electronics ,
Blue Tooth Access Point , IP Print Servers, Security Camera,Poe switch
Packaging & Shipping
* PE/polybag/box/customized, accept packing service
* 7-15 working days for production, Shipped by DHL/Fedex/TNT/UPS/EMS/Bangda,etc
Our Services
Warranty
Our Products are with good quality, all materials are new provided, 3 years warranty with good after-sale service.
Company Information
BTON is one of high- tech companies specialized in reasearching ,manufacturing and marketing of optical and fiber communication technologies. Dong Guan Doublex Electronics Industronics Co., LTD is BTON sister company . Doublex company is an experieced manufacturer of power adapter and switching power adapter and LED power supply driver etc,striving for a stable and energy efficient poduct .all power adapter have own certification.
Factory review
Part of our professional Certificate
FAQ:
1. OEM&ODM
2. Medium-sized enterprises, more cost-efficient and less administration fee
3. After-sales service 24/7
4. Offer customized service&production packing service
7. Are you a manufacture?
Yes ,100%.
8.what is MOQ?
50PCS.
9.What is the production lead time?
3-15 working days due to the production schedule.
Payment
1.We accept paypal ,West Union, TT ,Money Gram.
2.If you can't checkout immediately after auction close, please wait for a few minutes and retry Payments must be completed within 3 days.
Please contact us if our Trademanager is not online.
Skype: cocowei98
Trade manager:cn100226835
Cell Phone Number: +86-18617118649
