Product Name

9-Port PoE Switch with 8 PoE Ports and 1 SC Fiber Port

Product Model

POE31008PF

Connector

9x 10/100M copper cable RJ45 ports(all ports support MDI/MDIX)

8x PoE ports, 1x 155Mbps SC fiber port

Transfer Mode

Store-And-Forward

Network Medium

10BASE-T: Cat3,4,5 UTP(≤100 meter)

100BASE-TX: Cat5 or more UTP (≤100 meter)

Data transmission distance: 100m; Fiber transmission: 25km

Performance Specifications

Bandwidth: 1.6Gbps (non-blocking)
Network Latency (100 to 100M bps): maximum delay less than 20 microseconds
Packet Buffer Memory: 96KB
Address Database Size: 1,000
MTBF: 190,000 hours (about 21 years)

Network Protocols and Standards

IEEE 802.3i 10BASET
IEEE 802.3u 100BASETX
IEEE 802.3x Flow Control
IEEE 802.1af DTE Power via MDI
IEEE 802.3af

LEDs Status

System: power supply
Every Port: connecting, PoE working status

Power

Maximum PoE power: 120W
PoE port power:15.4 W(1~8 port)
Power input: AC100-240V 50/60Hz; (every country use a custom power plug)

Dimensions/Weight

Dimensions(LxWxH): 195x110x35mm, 0.52kg

Working Environment

Operating Temperature: 0 ° ~ 55 ° C

Storage Temperature: -20 ° ~ 75 ° C

Operating Humidity: 10% ~ 95%, non-condensing

Radiation

CE mark, commercial
FCC Part 15 Class B
VCCI Class B
EN 55022 (CISPR 22), Class B

Safety

CE Mark ,commercial
CE/LVD EN60950, RoHS

Warranty

1 year warranty(2 yeas warranty for power adapter)

Product Dimension Display
