24 Gigabit RJ45 Ports 2 Combo SFP Smart Managed Industrial Network Fiber Switch

24 Gigabit RJ45 Ports 2 Combo SFP Smart Managed Industrial Network Fiber Switch thumbnail-1
24 Gigabit RJ45 Ports 2 Combo SFP Smart Managed Industrial Network Fiber Switch photo-1
US$ 32 - 80 MOQ: 100 Pairs
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Bton
Model Number:
BT-3326G
Contact Supplier Request Quote Chat Now
Shenzhen Bton Weiye Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Bton
Model Number BT-3326G
Product Description

24 Gigabit RJ45 Ports 2 Combo SFP Smart Managed Industrial Network Fiber Switch

This managed industrial Ethernet switch is designed to match the critical industrial standards. With reliable and simple operation against vibration and shock, and wide operation temperature range, it could match a variety of harsh environments.
The switch complies with CE, FCC and RoHS standards, and passed the 100% burning test to ensure that it will fulfill the needs of industrial applications. It is a good choice for an economical solution for industrial Ethernet connections.


Features & Benefits
24 10/100/1000Base-TX ports and 2 1000Base-SX/LX/LH/ZX/SFP fiber port
10/100/1000M auto-negotiation , Full/Half duplex mode, auto-MDI-MDI-X
Super lightening protection, IP40 protection
Excellent heat elimination without cooling fan
Redundant dual DC power inputs
-40℃-85℃ operating temperature range
Switch Properties
MAC Table Size: 1K
Packet Buffer Size: 1Mbit
Processing Type: Store and Forward
Exchange Properties: 1488000pps (1000M)
Physical Characteristics
Housing: Aluminum Alloy material with IP40 Protection
Dimension: 1000mm(L) X 700mm(W) X 60mm(H)
Weight: 1200g
Installation: Din-Rail mounting, Wall mounting
Interfaces
24 RJ45 Ports
Comply with IEEE802.3, IEEE802.3u, IEEE802.3ab, 10/100/1000Base-TX
10/100/1000Base-TX auto negotiation speed
Full/Half duplex mode
Auto MDI-MDI-X connection
Power
Input Voltage: 24V DC(18-36VDC) Redundant dual inputs
Input Current: <0.5A @24VDC
Overload Current Protection: Present
Reverse Polarity Protection: Present
Redundant Protection: Present
Connection: 1 removable 6-pin terminal blocks
Environmental Limits
Operating Temperature: -40℃-85℃
Storage Temperature: -40℃-85℃
Ambient Relative Humidity: 5%-95% (non-condensing)
Technology
Protocol: BT-Ring, IGMPv1/v2, GVRP, SNMPv1/ v2C/ v3, DHCP Client, TFTP, SMTP, RMON, HTTP,
HTTPS, Telnet, Syslog, SSH, SNMP Inform, LLDP, SNTP Service/ Client, PVLAN
MIB: MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB
Group 1,2,3,9
Flow Control: IEEE 802.3x flow control, back pressure flow control
Standards
Safety: UL 60950-1
EMS:
EN61000-4-2 (ESD)，Level 3
EN61000-4-3 (RS)，Level 3
EN61000-4-4 (EFT)，Level 3
EN61000-4-5 (Surge)，Level 3
EN61000-4-6 (CS)，Level 3
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A
Industry: IEC61000-6-2
Rail: EN50155, EN50121-4
Traffic: NEMA TS-2
Warranty
5 years
Detailed Images

Features

4 10/100Base-T(X) ports and 4 100Base-FX ports

Power Charger type

British type,Amercian type,European type,Austrilia Type

Related Products
Packing & Delivery
Our Company

Shenzhen BTON Weiye Technology Co., Ltd is one of the powerful and high-tech companies specialized in researching, manufacturing and marketing of optical and fiber communication technologies. Our major products are media converter, digital video optical transmission systems and Optical Transceiver Modules .All of these products are widely applied in many industries like telecom ,traffic, government organization, campus network ,oil industry, electric power system, and public security etc. B&TON is one of the biggest and fastest growing multi products manufacturing and service provider(including OEM,ODM service and customized) in Shenzhen China
