Home > Products > butterfly valve > TKFM stainless steel manual or gear operation butterfly valve
TKFM stainless steel manual or gear operation butterfly valve
- 1000 Set / Sets per Month
- DALIAN
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Standard or Nonstandard: | Standard | Structure: | Butterfly | Pressure: | Low Pressure |
| Power: | Manual | Material: | Casting | Temperature of Media: | Medium Temperature |
| Media: | Water | Port Size: | DN50(2'')~DN450(18'') | Place of Origin: | Liaoning, China |
| Model Number: | D341X-16Q | Brand Name: | TKFM | Application: | General |
Product Description
TKFM stainless steel gear operated butterfly valve
Valve Standard:
Comply with ISO 5752/BS 5155/BS EN 593
Pressure Temperature Ratings
Work Pressure: 16 bar
Testing Pressure:Shell 24 bar
Seat: 17.6 bar
Working Temperature:-20°C to 110°C EPDM Seat
-10°C to 80°C NBR Seat
Suitable Media: Water,Oil & Gas
Material Specification:
| Part | Material | EN Spec. | |||
| Body | Ductile Iron | EN-JS 1050 | |||
| DISC | Ductile Iron | EN-JS 1050 | |||
| Bronze | EN 1982 CC491K | ||||
| Stainless Steel 304 | BS970 304 C15 | ||||
| Stainless Steel 316 | BS970 316 C16 | ||||
| Shell | Stainless Steel 410 | BS970 410 S 21 | |||
| Stainless Steel 431 | BS970 431 S 29 | ||||
| Seal Ring | EPDM/NBR | ||||
| O-Ring | EPDM/NBR | ||||
| Bushing | Bronze | EN 1982 CC491K | |||
Dimensions
| DN | mm | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 700 | 750 |
| Inch | 2 | 2½ | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 | 16 | 18 | 20 | 24 | 28 | 30 | |
| A | 80 | 80 | 95 | 114 | 114 | 139 | 175 | 203 | 250 | 250 | 310 | 332 | 358 | 423 | 479 | 508 | |
| B | 110 | 134 | 131 | 150 | 170 | 180 | 210 | 245 | 328 | 328 | 376 | 407 | 433 | 508 | 560 | 610 | |
| C | 30 | 30 | 30 | 30 | 30 | 30 | 34 | 34 | 40 | 40 | 52 | 52 | 64 | 70 | 95 | 95 | |
| L | 108 | 112 | 114 | 127 | 140 | 140 | 152 | 165 | 190 | 190 | 216 | 222 | 229 | 267 | 292 | 305 | |
| DN | mm | 800 | 900 | 1000 | 1200 | 1300 | 1350 | 1400 | 1500 | 1600 | 1800 | 2000 | 2200 | 2400 | 2600 | 2800 | 3000 |
| Inch | 32 | 36 | 40 | 48 | 52 | 54 | 56 | 60 | 64 | 72 | 80 | 88 | 96 | 104 | 112 | 120 | |
| A | 533 | 602 | 656 | 781 | 915 | 925 | 925 | 950 | 1041 | 1156 | 1350 | 1430 | 1610 | 1795 | 1900 | 2040 | |
| B | 620 | 692 | 735 | 917 | 990 | 1000 | 1000 | 1050 | 1150 | 1200 | 1360 | 1500 | 1650 | 1780 | 1900 | 2070 | |
| C | 95 | 130 | 130 | 150 | 150 | 200 | 200 | 200 | 200 | 200 | 200 | 300 | 300 | 300 | 300 | 350 | |
| L | 318 | 330 | 410 | 470 | 530 | 530 | 530 | 570 | 600 | 670 | 760 | 636 | 850 | 900 | 950 | 1000 | |
2015 TKFM low pressure flange connection 4 inch high performance ptfe butterfly valve
Terms of payment: 30% in advance as deposit, the balance paid before delivery.
Delivery time: 30 days after receiving the prepayment.
Terms of trading: FOB, CFR, CIF
Guarantee: 12 months
Fully welded ball valve - Company advantages:
1. We are factory: We have strict quality control system and amounts of testing equipments for different kind of valve, such as size, pressure, working environment etc. also can provide the competitive price.
2. Certification: API, CE, ISO,GOST, TS ..etc
3. Low MOQ: Our factory owns the casting company by itself. We are always ready for providing the sample and producing some small orders, in order to meet the business well.
4. OEM Accepted: We can make the products with the client's demand standard or the customer requirement.
5. Complete Service: We are always ready to hear from you, reply within 12 hours.
6. Quick Delivery: We always keep the large stock for some hot products.
TKFM stainless steel gear operated butterfly valve
1.What's payment terms? 30% payment in advance, 70% balanced before delivery. (if total value is USD$ 500, we suggest 100% payment in advanve.)
2.What's MOQ? One set. (if small size, we can check if free sample or not, freight need to be paid by customer.)
3.How control the quality of ball valve?
Select high quality raw material; Strict required during machining; Seat material comply with food grade; Tested twice to insure zero leakage; First copper plating disc, then nickle plating disc to increase the adhesiveness
4.Delivery time?
10-30 days after received the advance payment. (if stock, about 10 days)
