Specifications
1.API 11B sucker rod2.Size:5/8'', 3/4'', 7/8'',1'', 1 1/8''
ntinous,hollow&solid suker rod
Features:
Fuction:Sucker rod is a major component of pumping system , Above the pumping unit, then oil well pump the following which play a role of power transmission.the sucker rod which on the top of rod string called polished rod, wellhead sealed box and polished rod play a role of Wellhead seal airtight.
There are solid sucker rod and hollow sucker rod ,the length of sucker rod are usual 8m or so .our company have the ability to supply C Grade ,D Grade , K Grade sucker rod apply to the standard of API Spec 11B , also the hi-strength H Grade sucker rod on the basis of API.
Technical Parameters:
Type |
API Grade |
API Nominal (diameter) |
API length |
Weight kg/pc |
Quantity |
sucker rod |
Grade D
Grade C
Grade K
|
3/4 inch(19 mm) |
25 inch(7620 mm) |
18.38 |
100nos |
|
|
|
30 inch(9140 mm) |
21.77 |
100 nos |
|
|
7/8 inch(22 mm) |
25 inch(7620 mm) |
24.51 |
100 nos |
|
|
|
30 inch(9140 mm |
29.04 |
100 nos |
|
|
1 inch(25 mm) |
25 inch(7620 mm) |
32.36 |
50 nos |
|
|
|
30 inch(9140 mm) |
38.21 |
50 nos |
collar |
Grade T Grade SM
|
3/4 inch(19 mm) |
4 inch(101.6 mm) |
0.61 |
_ |
|
|
7/8 inch(22 mm) |
4 inch(101.6 mm) |
0.78 |
_ |
|
|
1 inch(25 mm |
4 inch(101.6 mm |
1.17 |
_ |
