1-channel video+audio+data+Ethernet+telephone+switch value fiber optic video converter
USD $1 - $30
/ Pair
1 Pair(Min.Order)
- 30000 Pair / Pairs per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
-
ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
-
ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
-
ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
-
ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
-
ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | BTON | Model Number: | BT-1V1DF-T/R |
Product Description
Digital Fiber Optical Video Converter ,1/2/4/8/16/32 Channels ,Audio Data Ethernet
| Specification |
| Video |
| Non-compression and no-distortion |
| Video standards: PAL/NTSC/SECAM |
| Frequency Response: 8MHz |
| Video connection: BNC |
| Signal to Noise Ratio: > 65dB |
| Optical |
| Optic wavelength: 1310/1550nm |
| Optic interface: FC/SC/ST(optical) |
| Supported |
| single mode: 9/125, multimode: 50,62.5/125 |
| Path Loss: 20dBm |
| Audio |
| Audio width: 20Hz~20KHz |
| Signal to Noise Ratio: > 85dB |
| Data |
| Data interface: RS-232, RS422 (full duplex), RS485 (half duplex) Manchester, Bi-phase |
| Data rate per channel: Up to 512kb/s |
| BER: <10-9 |
| General |
| power supply: DC5V/1A( optional) |
| operating temperature: -35°C~70°C |
| operating humidity:0~95% |
| Dimension |
| Stand alone: 105(L)×104(W)×28(H)mm |
| Color: Black |
| Material: Iron shell |
| Model | Description | Optical interface | Transmission distance(km) | Fiber Type |
| BT-1VF-T/RS | 1-channel video | FC ( optional SC/ST ) | 20 to 80 | Single or multimode |
| BT-1V1DF-T/RS | 1-channel video and 1-channel data | |||
| BT-2VF-T/RS | 2-channel video | FC ( optional SC/ST ) | 20 to 80 | Single or multimode |
| BT-2V1DF-T/RS | 2-channel video and 1 channel data | |||
| BT-4VF-T/RS | Mini 4-channel video | FC ( optional SC/ST ) | 20 to 80 | Single or multimode |
Products Display
BTON Company
Factory Display
Testing and Olding
Certificates
About us:
Shenzhen Factory-BTON is a manufacturer of Fiber Media Converter, Fiber Video Converter, SFP Module and Optic Fusion Splicer with good quality ,all products with CE/FCC/RoHS approved. Welcome to send inquiry to us.
Hope your business will be better and better,and all goes well with you !
Sherry
Shenzhen Bton Technology Co.,Ltd
Website: ww
Skype: btonnet04
Email. : sales4 (at)
Tel. : 86-755-23418351
Mobile: +86-13590418442
