Home > Products > Components of drilling rig > YC135 API Standard Oil Drilling Rig Parts Traveling Block for Oilfield
YC135 API Standard Oil Drilling Rig Parts Traveling Block for Oilfield
USD $5,000 - $20,000
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Qingdao
- T/T
You May Like
Product Details
Place of Origin: | Shandong, China | Brand Name: | Hongsheng Oil | Model Number: | YC135 |
Type: | Traveling Block | Machine Type: | Drilling Equipment | Certification: | API |
Material: | Other, According to your requirements. | Processing Type: | Other, According to your requirements. | Use: | Well Drilling |
Product Description
Specifications
1.Meet specification API 8C and the requirements of industry standard SY/T55272.With competitive price and after sales service
Product Features
ets specification API 8C.
2. pulley has been hardened, wear-resistant, long life.
3. meet the requirements of industry standard SY/T5527
4. pulleys and bearings and supporting crane interchangeable
Traveling Block Parameters
Model | YC90 | YC135 | YC170 | YC225 | YC315 | YC450 | YC585 | |
The maximum hook load | KN | 900 | 1350 | 1700 | 2250 | 3150 | 4500 | 5850 |
US ton | 100 | 150 | 200 | 250 | 350 | 500 | 650 | |
Outer diameter pulley | mm | 762 | 915 | 915 | 1120 | 1270 | 1524 | 1524 |
in | 30 | 36 | 36 | 44 | 50 | 60 | 60 | |
Pulley number | 4 | 4 | 5 | 5 | 6 | 6 | 7 | |
Rope diameter | mm | 26 | 26 | 29 | 32 | 35 | 38 | 42 |
in | 1 | 1 | 1 1/8 | 1 1/4 | 1 3/8 | 1 1/2 | 1 5/8 | |
Dimensions | mm | 1500×806 | 1800×960 | 2100×960 | 2294×1190 | 2680×1350 | 3075×1600 | 3100×1600 |
(Length × width × height) | ×533 | ×610 | ×630 | ×630 | ×974 | ×800 | ×965 | |
in | 59×32×21 | 71×38×24 | 83×38×25 | 90×47×25 | 105×53×38 | 121×63×32 | 122×63×38 | |
Quality | kg | 1810 | 2200 | 3010 | 3805 | 6842 | 8135 | 9600 |
Ib | 3990 | 4850 | 6636 | 8389 | 15084 | 17930 | 21160 |
