Vibrating quadrate screening machine
Main Usage
The machine consists of screen box at material inlet and outlet, vibrator and shock absorber.
There are 4-6 sets of flexible rubber shock absorber connected between base and screen box in up-down order. Centrifugal force is generated upon starting the machine. Control shock absorber against amplitude accentric device correspondingly for the best performance and material screening process in throwing vibration and loose. It is the ideal choice for pharmaceutical, food, chemical, metallurgy and electric industries.
Technical Data
Model |
ZS-0.5M2-X |
ZS-0.7M2-X |
ZS-0.8M2-X |
ZS-1.2M2-X |
Capacity(kg/h) |
450 |
650 |
750 |
1100 |
mesh |
2-150 |
2-150 |
2-150 |
2-150 |
Power(kw/h) |
0.2*2 |
0.2*2 |
0.2*2 |
0.2*2 |
Vibrating frequency (time/min) |
1400 |
1400 |
1400 |
1400 |
KN |
0-2.5*2 |
0-2.5*2 |
0-2.5*2 |
0-2.5*2 |
Upper output height |
800 |
850 |
850 |
880 |
Middle output height |
680 |
750 |
750 |
760 |
Under output height |
500 |
530 |
530 |
520 |
Overall size(l*w*h) |
1300*770*1060 |
1700*680*1100 |
1600*830*1150 |
1900*980*1220 |
Weight(kg) |
220 |
280 |
320 |
450 |
Material |
SUS304 |
SUS304 |
SUS304 |
SUS304 |
Detail Pictures of vibrating quadrate screening machine
Other Recommended
If you want other machines, please contact me !
If you want to send inquriy to me about our vibrating flour sifter , could you please tell me?
1) What material you want to grind, is it dry, what is the size of feed material ?
2) What capacity you expect ? (kg/h)
3) What mesh or mm or micron(size) of the powder you want?
4) What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p; 220V...etc.
(We only provide 3P, because our machines are all for industrial use,not for family.)
5) Usually we use stainless steel 304, if you want stainless steel 316, it's OK and please tell us.
Then our communication will be more efficient.
