Tractor Front Mounted Double Disk Rotary Mower :
This round disk mower just could work with single cylinder small four wheeled tractor,mainly suit for alfalfa,lawn grass harvesting.Depends on use rotary cutter,this mower more adopt to pasture,especially for thickset,laid or messy grass.More smoothly,high working efficiency.
Advantage:
This mower hitched in front of tractor,maily consist of linkage,lifting,cutting and so on,more simple,more compact structure,more adaptable and with low cost.
The lifting system was controled by tractor,connect the machine cylinder oil pipe with the tractor hydraulic system,control the tractor’s hydraulic lifting handle to finish the machine’s lifting.
The machine power was transmitted by tractor’s flywheel,and the two belts stay within the same plane,bring more compact structure.
This mower more easy for installation,more high efficiency,more easy operation,more wide supporting range.
In front of the machine, install with protective guard and protective cover.And make the dick blade to disk,control the blade in the same angle with the ground when rotating,and won’t hurt anybody if the blade fall off or fly off,more safety.
Main Tech Data:
Model |
Unit |
9GX-2F |
Cutting width |
mm |
1250 |
Stubble height |
mm |
≥30 |
Blade Q’ty |
pcs |
3*2 |
Working efficiency |
mu/h |
5-10 |
Working speed |
Km/h |
6-10 |
Driven type |
|
Belt driven |
Overall weight |
kg |
260 |
Matched power |
hp |
15-28 |
Linkage |
|
Tractor front mounted |
Other Mower Slasher:
ISO9001:2008 Certificate:
Ali Disc Harrow Co Factory:
Ali Disc Harrow Customers:
Any informations feel free to contact me,will sincerly be on your service!!!
