Specifications
2012 Top hot sale agricultural equipment of Rotary tillerMatched power:12-120hp
Working width:100-300cm
Overall weight:200
2012 Top hot sale agricultural equipment of Rotary tiller (Shandong Yucheng Ali Disc Harrow Co.,Ltd):
Uses:
It adopts middle gear transmission system,which mounted with the tractor of 12-80HP.Tractor's wheel tracks are completely covered after tillage as the working width is much wider.
Features:
The quality is reliable and the performance is well.So it can be used on dry and paddy field.It can reduce the time,labor and cost .etc
Main specifications:
Modle |
1GQN-100 |
1GQN-125 |
1GQN-140 |
1GQN-150 |
1GQN-160 |
1GQN-180 |
1GQN-200 |
1GQN-220 |
1GQN-250 |
1GQN-300 |
||
1GN-100 |
1GN-125 |
1GN-140 |
1GN-150 |
1GN-160 |
1GN-180 |
1GN-200 |
1GN-220 |
1GN-250 |
1GN-300 |
|||
Matched power(hp) |
12-15 |
18-20 |
20-25 |
25-30 |
30-40 |
50-55 |
55-75 |
60-80 |
75-80 |
80~120 |
||
Working width(cm) |
100 |
125 |
140 |
150 |
160 |
180 |
200 |
220 |
250 |
300 |
||
Working depth(cm) |
Dry land |
12-16 |
12-18 |
|||||||||
|
paddy field |
14-16 |
14~20 |
||||||||||
|
NO. of blades |
22 |
26 |
30 |
34 |
38 |
50 |
54 |
58 |
62 |
76 |
||
|
Type of blade |
IT225 |
IT245 |
||||||||||
|
(kg) Total weight |
200 |
220 |
230 |
240 |
260 |
415 |
430 |
445 |
460 |
520 |
||
192 |
210 |
220 |
230 |
248 |
405 |
420 |
435 |
450 |
450 |
|||
|
(mm) Dimension |
(L) |
900 |
900 |
900 |
900 |
900 |
1020 |
1020 |
1020 |
1020 |
1020 |
|
(W) |
1050 |
1350 |
1500 |
1600 |
1700 |
1900 |
2100 |
2300 |
2600 |
3100 |
||
(H) |
950 |
1000 |
1000 |
1000 |
1000 |
1152 |
1152 |
1152 |
1152 |
1152 |
||
Linkage |
(Standard three-point mounted) |
|||||||||||
2012 Top hot sale agricultural equipment of Rotary tiller
