Specifications
2013 hot seller tractor rotary tiller1.ideal for swamp field
2.deliver power by tractor's rear PTO
Product information:
2013 hot seller tractor rotary tiller
1LYQ series of rotary-driven disc plough is mounted with tractor by the rear 3-point suspension ,device and drives the plough discs to revovle in the way of delivering power by tractor’s rear PTO to the disc plough’s gear box.This machine is mainly suitable for cultivation on paddy field with the advantages of non-tangling weeds,high quality and efficiency.
Model |
Unit |
1LYQ-422 |
1L-522 |
1LYQ-622 |
1L-722 |
1LYQ-822 |
|||||
Overall dimension |
mm |
965*1365* 1050 |
1075*1585* 1050 |
1210*1805* 1050 |
1325*2025* 1050 |
1440*2245* 1050 |
|||||
Working width |
mm |
880 |
1100 |
1320 |
1540 |
1760 |
|||||
Working depth |
mm |
200-240 |
|||||||||
|
Rotating speed of input shaft |
r/min |
540/720 |
|||||||||
|
Rotating speed of cutter shaft |
r/min |
90~120 |
|||||||||
Matched power |
hp |
18~22 |
25~30 |
40~50 |
50~60 |
60~70 |
|||||
Company Introduction:
Shandong Yucheng Ali Disc Harrow Co., Ltd, a private enterprise specializing in developing, selling and producing the agricultural machinery, the drafter of the industry standard of the disc harrow and share plough in China, which is China's outstanding agricultural expert;
ISO9001:2000 quality management system certification.
Covers an area of 32000 square meters including more than 15000 square meters standard workshops. There are 120 sets of various machinery equipments,158 employees and 66 engineers and technicians.
We mainly produce disc harrow, disc plough, share plow, rotary tiller, potato planter, potato harvester, cultivator, subsoiler, seeder, box blade, rigger, ditcher, stubble cleaner, hole digger, fertilizer spreader, farming trailers and so on. We can yearly produce 20,000 sets of complete machines for each specification and 300,000pcs of plough discs and harrow discs. Which are exported to more than 66 countries, such as USA, France, Germany, Russia, Switzerland, Zimbabwe, Ukraine, Nigeria, and South America.
