1GQN Rotary Tiller Farm Machinary

Specifications

Product Specification:

1GQN rotary cultivator

1GQN rotary cultivator is a farming machine matched with 12-80 horsepower tractors, and adopts big plowing width and symmetric suspension to cover wheel tracks completely. The machine has the characteristics of reliable quality, excellent performance, suitability for operation in dry field and paddy field, time conservation, labor conservation, high operation quality, low cost, etc.

Model			1GQN-100	1GQN-125	1GQN-140	1GQN-150	1GQN-160	1GQN-180	1GQN-200	1GQN-220	1GQN-250	1GQN-300
			1GN-100	1GN-125	1GN-140	1GN-150	1GN-160	1GN-180	1GN-200	1GN-220	1GN-250	1GN-300
Matched Power (hp)			12-15	18-20	20-25	25-30	30-40	50-55	55-75	60-80	75-80	80~120
Plowing Width (cm)			100	125	140	150	160	180	200	220	250	300
Plowing Depth (cm)	Dry Field		12-16					12-18
	Paddy Field		14-16					14~20
Quantity of Blades			22	26	30	34	38	50	54	58	62	72
Model of Blades			IT225					IT245
Weight of Complete Machine (kg)			200	220	230	240	260	415	430	445	460	520
			192	210	220	230	248	405	420	435	450	450
Overall Dimensions (mm)		Length (L)	900	900	900	900	900	1020	1020	1020	1020	1020
		Width (W)	1050	1350	1500	1600	1700	1900	2100	2300	2600	3100
		Height (H)	950	1000	1000	1000	1000	1152	1152	1152	1152	1152
Mounting Form			standard three-point mounting







Company Introduction:

 Shandong Yucheng Ali Disc Harrow Co., Ltd, a private enterprise specializing in developing, selling and producing the agricultural machinery, the drafter of the industry standard of the disc harrow and share plough in China, which is China's outstanding agricultural expert;

 ISO9001:2000 quality management system certification.

Covers an area of 32000 square meters including more than 15000 square meters standard workshops. There are 120 sets of various machinery equipments,158 employees and 66 engineers and technicians.

We mainly produce with the brand of “QINGQUAN”: disc harrow, disc plough, share plow, rotary tiller, potato planter, potato harvester, cultivator, subsoiler, seeder, box blade, rigger, ditcher, stubble cleaner,     hole digger, fertilizer spreader, farming trailers and so on. We can yearly produce 20,000 sets of complete machines for

each specification and 300,000pcs of plough discs and harrow discs. Which are exported to more than 66 countries, such as

USA, France, Germany, Russia, Switzerland, Zimbabwe, Ukraine, Nigeria, and South America.
