3-Point Mounted 6 Plate Rotary Hay Raker:
This series of hay rake is mounted on the 4 wheel tractor,the material of tine is 65Mn spring steel to keep durable.This machine has simple structure,convenient operation and reliable use,less failure and high efficiency.Operation quality maintenance is simple,dynamic performance is good.Both can hug grass,and ted the grass.This hay rake could be used together with our lawn mower,it can rake the three grass swath which cut to be a even one,that is helpful for the subsequent bundling work.
Feature:
It is 3-point mounted hay rake for 4 wheel tractor.
This tractor hay rake has 65Mn rake tines.
The number of tine plates 4-13 to meet different condition of farm field.
Main Specification:
Model |
Unit |
9GLTS-3.0 |
9GLTS-4.0 |
9GLTS-4.8 |
9GLTS-6-11 |
9GLTS-7-13 |
Working width |
mm |
3000 |
4000 |
4800 |
7400 |
8200 |
Fitted power |
hp |
20-25 |
25-30 |
55 |
80-100 |
90-120 |
Tine Q’ty for each drum |
pcs |
40 |
40 |
40 |
40 |
40 |
Q’ty of drum |
pcs |
4 |
6 |
8 |
11 |
13 |
Dia. Of drum |
mm |
1460 |
1460 |
1460 |
1460 |
1460 |
Width of windrow |
mm |
0.9-1.2 |
1-1.3 |
1-1.5 |
1.5-2.0 |
1.5-2.0 |
Total weight |
kg |
150 |
295 |
345 |
1100 |
1300 |
Linkage |
|
Standard three point mounted |
Hydraulic trailed |
|||
Relevant products pictures:
ISO9001:2008 Certificate:
Ali Disc Harrow Factory:
Ali Disc Harrow Customers:
Shipping:
1. FOB Qingdao
2. CFR & CIF your port
3. Others as customer's require
Payment:
1.By T/T
2.By L/C
About our company:
[1] Our company Shandong Yucheng Ali Disc Harrow Co.,Ltd, a private enterprise specializing in developing,
selling and producing the agricultural machinery, which is China's outstanding agricultural
expert, we have self-supported import and export right.The quality of our products is reliable and
the performance is well.The main products of our company include: Ali Disc Harrow brand disc harrow, disc plow, mouldboard plow, rotary tiller, potato planting (harvest) machine, cultivator, subsoiler, seeder, leveler, ridger, trencher, stubble cleaner, earth auger, fertilizer distributor, farm trailer, and the other farm machinery.
[2] Our company has passed ISO9001.2008 quality system certification .
[3] Our company located in Shandongyucheng high and new technology,Our products are exported to Amecica,France,Germany,Russia,Nigeria and so on .
Thank you for your attention on our products and also our company, and we hope that these informations will be helpful to you.
For more informations please feel free to contact us!
Contact Person: May Sun
QQ: 2253692868
Wechat: 1012214575
Skype: maysun1989
WhatsApp: 15864176598
Mobile: 86-15864176598
Address: Yucheng High & New Technology Development Zone, Dezhou, Shandong, China (Mainland)
