Home > Products > AC Inlet / Power socket > IEC C14 socket with switch&socket with cover
IEC C14 socket with switch&socket with cover
- 5000 Piece / Pieces per Month
- shenzhen
- T/T
- 4holes RCA jack AV socket
- AV socket AV6 double-six-hole socket RCA jack video with metal
- Good quality single socket RCA as AV connector
- 4 holes jack socket RCA as AV connector
- Bluetooth 4.0 Wireless Anti lost alarm with Bluetooth Remote control for iPhone Samsung smartphone
- KDC-A04 Power Switch 4pin
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Ganhad | Model Number: | ST-A01-004DL |
Type: | Electrical Plug | Grounding: | Non-Grounding | Rated Voltage: | 250VAC |
Rated Current: | 10A/15A | Application: | Industrial |
Product Description
Specifications
1.18 years manufacturing experience.2. UL .cUL.VDE. ENEC approved.
3. comply with ROHS/HF.
4. Design as requirement
IEC C14 socket with switch&socket with cover :
Spec.:
Rating : | 15A 250VAC |
10A 250VAC | |
Standards | UL498,IEC60320,GB17465 |
Initial contact resistance: | 20mΩ max |
Insulation resistance: | 100 mΩ (min)for DC 500V |
RoSH,HF | |
Working temperature: | ≤105°C |
Housing : | PA66/PC/PBT |
Terminals: | Tin-plated brass |
Factory detail:
Shenzhen Ganhad Plastic Electronics Co.,Ltd: Established in 2001, our factory
has been focusing on switch over a decade, our products are mainly to America, Europe,
Asia and Middle East.
Application: Our switches are widely used in the fields of small household products,
communication equipment, energy generator, electric tools, table lamp, electric motor,
electric motor car, electric toy, UPS, medical facilities, socket, etc
Engineering: We serve product design, mould development, plastic part injection,
hardware part pressing and product automatic assembly
Quality: We will inspect supplied material, production process and final product,
we completely make quality control for every pass with inspections including withstand
voltage, insulating resistance, conductor, dimension, external appearance, etc. Meanwhile
random sampling is taken for inspections such as products' exotherm, environmental
protection and electrical life. All related raw materials are inspected according to ROHS detective.
Brand: We strive to maintain PRO-SW as our brand and to make professional switch.
