C20 Electrical Plugs and Sockets

C20 Electrical Plugs and Sockets thumbnail-1
C20 Electrical Plugs and Sockets photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Ganhad
Model Number:
R-3012
Contact Supplier Request Quote Chat Now
Shenzhen Ganhad Plastic Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Ganhad
Model Number R-3012
Type Electrical Plug
Grounding Non-Grounding
Rated Voltage 15A 125V AC
Rated Current 10A 250V AC
Application Industrial

Specifications

1. C20 electrical plugs and sockets
2. UL .cUL.VDE. ENEC approved
3. comply with ROHS/HF
4. Design as requirement

C20 electrical plugs and sockets :

C20 electrical plugs and socketsC20 electrical plugs and sockets





Specification:





Rating : UL cUL :15A 125V AC
  VDE CCC: 10A 250V AC
Initial contact resistance: 20mΩ max
Insulation resistance: 100 mΩ (min)for DC 500V
Withstand voltage: 1500V AC for terminal to terminal 1minute
  3000V AC for terminal to body 1minute
Working temperature: ≤105°C
Housing : Pa66/PC/PBT
Terminals: Tin-plated brass



Factory detail:



C20 electrical plugs and socketsC20 electrical plugs and sockets









Shenzhen Ganhad Plastic Electronics Co.,Ltd: Established in 2001, our factory

has been focusing on switch over a decade, our products are mainly to America, Europe, Asia and Middle East.



Application: Our switches are widely used in the fields of small household products,

communication equipment, energy generator, electric tools, table lamp, electric motor,

 electric motor car, electric toy, UPS, medical facilities, socket, etc



Engineering: We serve product design, mould development, plastic part injection,

hardware part pressing and product automatic assembly







Quality: We will inspect supplied material, production process and final product, we completely

 make quality control for every pass with inspections including withstand voltage, insulating

resistance, conductor, dimension, external appearance, etc. Meanwhile random sampling is taken

 for inspections such as products' exotherm, environmental protection and electrical life.

All related raw materials are inspected according to ROHS detective.



Brand: We strive to maintain PRO-SW as our brand and to make professional switch.







C20 electrical plugs and socketsC20 electrical plugs and sockets
