Home > Products > AC Inlet / Power socket > IEC 15Amp AC Inlet Connector Socket&VDE UL Approved AC Jack.
IEC 15Amp AC Inlet Connector Socket&VDE UL Approved AC Jack.
- ShenZhen OR HongKong
You May Like
Product Details
| Place of Origin | China | Brand Name | Ganhad | |
| Model Number | ST-A01-004L | Type | Plug with Socket | |
| Grounding | Standard Grounding | Rated Voltage | 250 | |
| Rated Current | 15A | Application | Industrial |
Product Description
Specifications
UL .cUL.VDE.SAA.EK.SAA approved ,comply with ROHS/HF ..SPECIFICATION
Rating | 15A 250VAC 10A 250VAC |
Standards | UL498, IEC60320,GB17465 |
Initial Contact Resistance | 20mΩ max. |
Insulation resistance | 100MΩ (min) for DC 500V |
Withstand voltage | 1500VAC for terminal to terminal 1 minute 3000VAC for terminal to body 1 minute |
Working temperature | ≤105°C |
Main material | Housing : PA66 , PBT , PC |
Terminals : Tin-plated brass | |
Certificates | UL.CUL,CCC,VDE,SEMKO,NEMKO,FIMKO,DEMKO.SAA,EK |
