Trailed hydraulic heavy duty disc harrow
Production Description
* High hardness material in use.
* With spare parts is available.
* This machine is mostly used in farming work.
*Send into the market after field test.
*Professional manufacturer in China
Model |
unit |
1BZ-1.8 |
1BZ-2.2 |
1BZ-2.5 |
1BZ-3.0 |
1BZ-3.4 |
1BZ-4.0 |
1BZ-5.3 |
|
Working width |
m |
1.8 |
2.2 |
2.5 |
3.0 |
3.4 |
4.0 |
5.3 |
|
Working depth |
mm |
180~200 |
180~200 |
180~200 |
180~200 |
180~200 |
180~200 |
180-200 |
|
Q’ty of disc |
16 |
20 |
24 |
28 |
32 |
36 |
48 |
||
Disc diameter |
mm |
660 |
660 |
660 |
660 |
660 |
660 |
660 |
|
total weight |
kg |
1100 |
1250 |
1350 |
1450 |
1550 |
1700 |
1800 |
|
Matched power |
hp |
≥70 |
≥80 |
80~100 |
100~120 |
120~150 |
140~160 |
150-180 |
|
Linkage |
(Trailed ) |
||||||||
Model |
unit |
1BJX-1.8 |
1BJX-2.0 |
1BJX-2.2 |
1BJX-2.4 |
1BJX-2.5 |
Working width |
M |
1.8 |
2.0 |
2.2 |
2.4 |
2.5 |
Working depth |
mm |
140 |
140 |
140 |
140 |
140 |
Q’ty of disc |
16 |
18 |
20 |
22 |
24 |
|
Disc diameter |
mm |
560(610) |
560(610) |
560(610) |
560(610) |
560(610) |
Total weight |
kg |
390 |
434 |
463 |
604 |
760 |
Matched power |
hp |
45 |
50 |
55~65 |
65~75 |
80 |
Linkage |
Standard three-point mounted |
|||||
Model |
unit |
1BQX-1.1 |
1BQX-1.3 |
1BQX-1.5 |
1BQX-1.7 |
1BQX-1.9 |
1BQX-2.3 |
Working width |
m |
1.1 |
1.3 |
1.5 |
1.7 |
1.9 |
2.3 |
Working depth |
mm |
120 |
|||||
Q’ty of disc |
12 |
14 |
16 |
18 |
20 |
24 |
|
Disc diameter |
mm |
460 |
460 |
460 |
460 |
460 |
460 |
Total weight |
kg |
200 |
220 |
240 |
260 |
310 |
360 |
Matched power |
hp |
12 |
15 |
25 |
30~35 |
35~45 |
50 |
Linkage |
Standard three-point mounted |
||||||
Model |
Unit |
LCBB-2024 |
LCBB-2428 |
LCBB-2834 |
Working width |
mm |
2.4 |
2.8 |
3.4 |
Working depth |
mm |
200/220 |
200/220 |
200/220 |
Q’ty of disc |
20 |
24 |
28 |
|
Disc diameter |
mm |
660*6/710*8 |
660*6/710*8 |
660*6/710*8 |
distance between discs |
mm |
240 |
240 |
240 |
Linkage |
Trailed
|
Trailed
|
Trailed
|
|
Tyre type |
7.50-16/11L-15 |
7.50-16/11L-15 |
11L-15/400*60-15.5 |
|
Overall weight |
1800/2000 |
2100/2350 |
2400/2700 |
|
Matched power |
Hp
|
80-120 |
120-160 |
180-220 |
Details show:
This series of LCBB hydraulic trailed offset heavy,duty disc harrow is mainly applicable to clean the crop residue before tillage, break the hardened and impervious soil surface, crush and spread straw into the field, shatter soil after tillage, and level the land and preserve soil moisture. It can be used as tillage machine instead of plough on the cultivated land. With the efficient productivity, reasonable utilization of the power, great ability of cutting and shattering the soil , the soil surface is smooth and loosening after harrowing, it is well suitable for heavy clay soil, waste land and weedy field as well.
Shipping:
1. FOB Qingdao
2. CFR & CIF your port
3. Others
Payment:
1.By T/T
2.By L/C
Packing
*After inspection the machine was carefully packed in a iron net box.
Certification
About US
We have more than 10years experiences on farm equipments. We are a typical China manufacturer & supplier and have worked for tractor makers and trading company all over the world.
FAQ:
| Q1: Are you a factory or trading company? |
|---|
|
We are a factory with self-supported import and export right.
|
| Q2: How can I trust on your company? |
|
We are a fully registered manufacture and exporting company by China Export Registration Authorities. Moreover, our products have been exporting to a number of countries including Switzerland, Russia, Spain, Netherlands, Australia, Peru, Thailand, Pakistan, Indonesia, Tanzania, Nigeria, South Africa, Sudan, Congo etc. The good faith, punctual, strict quality control and reasonable price, throughout is the pledge we to each customer.
|
| Q3: Where is your factory located? How can I visit there? |
|
Our factory is located in Yucheng City, Shandong Province, China. About 1 hour away from Jinan Airport. All our clients are warmly welcomed to visit us!
|
| Q4: How can I place an order from your website? |
|
It is very easy.Once you find the implement you need on our website and place an inquiry against it, or, get to the inquiry section and leave us a message there with name, country and phone number, we will get in touch with you at the earliest. You can also e-mail us directly or join us on live chat for instantaneous answers.
|
| Q5: How can I make the payment? |
|
Payment is made via Telegraphic Transfer (T/T) through the bank against the proforma invoice.
|
| Q6: What's the Payment terms? |
|
FOB, the price of the implement without sea shipment costs. CIF, including the unit cost + marine insurance + Shipment charges to your destination port. CFR, including the unit cost + Shipment charges to your destination port.
|
| Q7: At which port do you usually ship the good? |
|
We usually ship goods via Qingdao, Shanghai, Ningbo, Tianjin port of China.
|
| Q8. How about the Warranty ? |
| 12 months warranty from the time of the goods arrive at destination. |
