Help CenterCE ROHS Approoved 5VA 2*18V Low Profile Miniature Toroidal Transformer, Low Profile Toroid, Low Profile Ring Core Transformer
Related Products
-
CE ROHS Approoved 7VA 2*7V Low Profile Miniature Toroidal Transformer, Low Profile Toroid, Low Profile Ring Core TransformerUS$ 1 - 10MOQ: 200 Pieces -
CE ROHS Approoved 10VA 2*12V Miniature 50/60Hz Power Transformer, Low Profile Toroid, Low Profile Ring Core TransformerUS$ 1 - 10MOQ: 200 Pieces
-
CE ROHS Approoved 15VA 2*12V Miniature 50/60Hz Power Transformer, Low Profile Toroid, Low Profile Ring Core TransformerUS$ 1 - 10MOQ: 200 Pieces
-
CE ROHS Approoved 25VA 2*9V Miniature 50/60Hz Power Transformer, Low Profile Toroid, Low Profile Ring Core TransformerUS$ 1 - 10MOQ: 200 Pieces
-
CE ROHS Approoved 35VA 2*15V Miniature 50/60Hz Power Transformer, Low Profile Toroid, Low Profile Ring Core TransformerUS$ 1 - 10MOQ: 200 Pieces
1. General description of 5VA 2*18V low profile miniature toroidal transformer, low profile toroid, low profile ring core transformer
- 110/230v 60Hz Primary;
- Two secondaries 18v, 139ma, (No load 25.5v, 2ma),
- 70% eff. For 110v supply power, primaries must be parallel; for 230v operation, primaries must be in series.
- OD: 47.mm ID: 6.mm x 18mm H
- Very Small size and low weight compared with traditional stacked lamination types.
- Extremely low level of radiated magnetic field
- Very low induced noise (hum)
- Very low iron loss.
- Double insulated primary leads.
- 100% electrical and flash tested
- Primary-Secondary test voltage 4.0 KV.
- Tapped primary for 115V OR 230V.
- Secondaries for parallel or series hookup.
- Ambient operating temperature +60 °C
- Maximum.Insulation Class A (105 °C)
- Meets all requirements of Class E(115°C).
3. low profile miniature toroidal transformer, low profile toroid, low profile ring core transformer schematic
4. Full assembly of low profile miniature toroidal transformer, low profile toroid, low profile ring core transformer
5. Details of low profile miniature toroidal transformer, low profile toroid, low profile ring core transformer
low profile miniature toroidal transformer, low profile toroid, low profile ring core transformer Packing
Strong cartons on plastic pallets.
1) We supply our customers free samples and generally low profile miniature toroidal transformer, low profile toroid, low profile ring core transformer ' samples can be finished within one week. But our customers will be required to pay for the samples shipping charge to customer's destination
2) We give our customers 2-year product warranty to better protect our customers' interests
3) 24 hours english hotline, 86-13207512928, for any product inquiry, after sales service or technical issues.
4) OEM and ODM are welcome
5) Factory visiting are warmly welcome
Our factory corners for low profile miniature toroidal transformer, low profile toroid, low profile ring core transformer
Trade show we sent to
