Specifications
Lifting column:1) 24V input voltage
2) 800N load
3) 717 strokes (option)
4) Built-in limit switches
1)The concept of lift tables: |
The free to lift the height of the table, sitting lift tables, lifting marginally suitable for different height users, the common use of the high-rise in the growth of children study table; class is sit stand alternately lift tables, lift amplitude, sitting in the office and standing office two modes can be realized. With the popularization of computers, the concept of lift tables has been further extended desktop fixed, monitor and mouse and keyboard can sit a computer station lift lift table (Platforms), and under certain circumstances, for computer operating lifting equipment installed wheels, lift mobile workstation (computer hand trolleys). |
2)Lift Mode |
The lift is generally divided into: electric, manual, foot pedal, pneumatic, hydraulic, and more of the first three methods used in the table above. Among them manually is more common, especially the use of innovative technology lift tables adjust very convenient. |
3)Lifting table Give an example |
A) CF manually adjust lift tables The lift tables using CF patented technology, without any tools and power plant can achieve instant transformation of sitting and standing! Integrated brakes fixed firmly on the work surface, just lightly touched on the height adjustment. B) sit-stand work table Many people choose to lift the table, the purpose is to use the office computer can switch sit to station two working posture to eliminate sedentary harm to guarantee the health of the body. The design of this monitor stand sit-stand table jumped out of the the traditional desktop lift design ideas, monitor and mouse and keyboard directly to achieve the lift in case the user does not need to replace the table to achieve alternating office chair stand (station style office). C) Mobile lifting computer workstation Specifically designed for computer users, not only the screen and the mouse and keyboard can be lifted freely, and to install a removable wheels, making it more suitable for use in the field of health care, education, and factories, removable lift computer workstations. |
4)The benefits of using lifting table |
Disease disease prevention of cervical, lumbar, buttocks, back, body, lose weight. Change the traditional sitting office, learning styles, so that office, learning, entertainment and so become more humane, can significantly improve work efficiency. Want to stand on the station, to ride with ease favorable physical and mental. 4 are suitable for men, women and children. Prevention sedentary men and women caused genitourinary diseases, such as prostatitis female urethral syndrome, infertility. Lift tables are long-term desk, Internet, stocks, entertainment and other kinds of people's health partner. Deeply cervical spondylosis, shoulder vertebra disease and other illnesses trapped stir the working population health Gospel. Lift tables is increasingly being recognized by the government, enterprises, schools and other institutions, and have advocated the use of. |
Automatic lifting table application:Classic fashion, suitable for office, conference room, command center, control room, central control room, product demonstration hall, multimedia report hall and so on each kind of upscale places. | |
5) lifting column specification |
|
6) input voltage: |
110/220VAC, output: 24VDC. |
7)Load capacity: |
1000N |
8)No load speed: |
38mm/s(800N) |
9)Type of duty: |
25% |
10)Ambient temperature: |
-25°C~65°C |
11)Protection class: |
IP54 |
12)<HT801KD> Stroke: |
465mm |
13) <HT801KD>Minimum height: |
665mm |
14) <HT801KD>Maximum height: |
1130mm |
15) <HT802KD> Stroke: |
650mm |
16) <HT802KD> Minimum height: |
560mm |
17) <HT802KD>Maximum height: |
1210mm |
18)Low noise design, |
db<53 |
19)Certification: |
CE,ROHS |
20)Colour: |
Black or gray |
