CE Approved 23 Seats Electric Tourist Bus With Price Factory Offer DN-23(China)

Name: CE Approved 23 Seats Electric Tourist Bus With Price Factory Offer DN-23(China)
Brand: Marshell
SKU: 112865185

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Marshell

Model Number:

DN-23

Shenzhen Marshell Green Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai or shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Marshell

Model Number DN-23

CE approved 23 Seats electric tourist bus with price factory offer DN-23(China)

1. Standard color: White;arractive design and powerful in appearance , with strong carrying capacity and lower noise.

2. Standard feature: Front and Rear lights; Rear View mirrors; Electric Horn; Rustproof body structure

3. Small turning radius; and smart steering system ;Whole style steel rear axle;

4. Can be easy modified to transportation vechicles,

5. CE certificate for whole carts;

6. Import main parts:US batteries( From USA) and Curtis controller(From USA).Delta-Q chargers(From Canada)

7. Four wheels hydraulic braking system and independent parking brake

Model	DN-23
Passenger Capacity	23
Power supply
Battery	6V battery *24pcs
Motor	51V9KW/AC
Controller	72V550A
Charger	2*48V25A full automatic high frequency charger
Performance
Max. Speed	25km/h
Max.travelling range	120km
Climbing capactity	15%
Brake Range	<=6
Minmum turning radius	8.5m
Gross Weight	2130kg
Carrying capacity	1750kg
Chassis
Steering	recirculating-ball steering
brakes	Four wheels hydraulic braking system and independent parking brake
tire	195/70R15C
Ground clearance	100mm
Overall dimension(Lwh)	560021002205mm
Qty per container	1pcs/20FT 2pcs/40FT 2pcs/40HQ
Standard parts	Front and rear lights Rear view mirrors Speed meter Wiper Power assisted steering system AC system
Optional parts	Loud speaker CD player Weather enclosure Side sunshade curtain 3 points seat belt for driver, Trojan Battery
