adapter sleeve bearing NSK adapter sleeves H2310
- 50000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
- 162250 GA CYLINDRICAL ROLLER BEARING High Speed Wire Rod Rolling Mill Bearing
- F-546485.01. KL-H95 DEEP GROOVE BALL BEARING High Speed Wire Rod Rolling Mill Bearing
- Z-507333.ZL Four-row cylindrical bearings High Speed Wire Rod Rolling Mill Bearing
- Z-504547.ZL Cylindrical Roller Bearing Multi Row High Speed Wire Rod Rolling Mill Bearing
- Z-533575.ZL Four - row Cylindrical roller bearing High Speed Wire Rod Rolling Mill Bearing
- 507335.KL Deep Groove Ball Bearing High Speed Wire Rod Rolling Mill Bearing
Product Details
Brand Name: | NSK | Bore Size: | 50, | Model Number: | H2310 |
Precision Rating: | PO P4 P5 P6 | Seals Type: | NO | Place of Origin: | Jiangsu, China |
Product Description
Specifications
NSK adapter sleeve H23101,rich stock
2,bearing manufacture
3,offer free samples
4,Deliver in time
Description of Adapter Sleeve:
bearing accessories,
rolling bearing accessories
withdrawal sleeves,
locknuts, lock washer, etc
Feature of Adapter Sleeve:
1. Allows maintenance-free and long-life operation
2. Suitable for high static and dynamic loads
3. With low and smoothly coefficient of friction and without stick-slip effects
4. Suitable for dirty, corrosion, impact load and edge loading
5. The base material provided a good shock-absorbing capacity
6. Can be used over a large temperature range
7. Suitable for reciprocating, rotating and oscillating movement with start frequency and difficulty to form oil film occasions
8. With low wear rate and long life service
Allows maintenance-free and long-life operation
Type of Adapter Sleeve:
Adapter sleeve (H) --
Adapter sleeves are the most commonly used components for locating bearings that has a tapered bore, onto cylindrical shaft seating’s as they can be employed both on smooth shafts and stepped shafts.
They are easy to mount and require no additional fixation on the shaft. Using adapter sleeves on smooth shafts, the bearing can be located at any position on the shaft . EESCO adapter sleeves are supplied complete with lock nut and locking device
Adapter sleeve for oil injection (OH) --
These sleeves have an oil supply duct (or ducts) at the threaded side of the sleeve and distributor grooves in the bore as well as the outside surface.
Sleeves up to and including size 40 have on supply duct, larger sleeves have two.
Adapter Sleeve :
Detailed Adapter Sleeve Product Show:
Part of adapter sleeve detail dimensions:
Adapter Sleeve | Shaftd1 | Dimensions(mm) | Weight (kg) | Composition | |||||||||
HS in | HA in | HE in | H mm | d | d2 | B1 | B2 | G | Sleeve | Locknut | Lockwasher | ||
H304 | 17 | 20 | 32 | 28 | 7 | M20x1 | 0.045 | A304 | KM4 | MB04 | |||
H305 | 7/8 | 13/16 | 3/4 | 20 | 25 | 38 | 29 | 8 | M25x1.5 | 0.075 | A305 | KM5 | MB05 |
H306 | 7/8 | 15/16 | 1 | 25 | 30 | 45 | 31 | 8 | M30x1.5 | 0.11 | A306 | KM6 | MB06 |
H307 | 1-1/8 | 1-3/16 | 1-1/4 | 30 | 35 | 52 | 35 | 9 | M35x1.5 | 0.14 | A307 | KM7 | MB07 |
H308 | 1-3/8 | 1-5/16 | 1-1/4 | 35 | 40 | 58 | 36 | 10 | M40x1.5 | 0.19 | A308 | KM8 | MB08 |
H309 | 1-5/8 | 1-7/16 | 1-1/2 | 40 | 45 | 65 | 39 | 11 | M45x1.5 | 0.25 | A309 | KM9 | MB09 |
H310 | 1-5/8 | 1-11/16 | 1-3/4 | 45 | 50 | 70 | 42 | 12 | M50x1.5 | 0.3 | A310 | KM10 | MB10 |
H311 | 1-7/8 | 1-15/16 | 2 | 50 | 55 | 75 | 45 | 12 | M55x2 | 0.35 | A311 | KM11 | MB11 |
H312 | 2-1/8 | 2-1/16 | 2-1/4 | 55 | 60 | 80 | 47 | 13 | M60x2 | 0.39 | A312 | KM12 | MB12 |
H313 | 2-3/8 | 2-3/16 | 2-1/4 | 60 | 65 | 85 | 50 | 14 | M65x2 | 0.46 | A313 | KM13 | MB13 |
H314 | 60 | 70 | 92 | 52 | 14 | M70x2 | 0.72 | A314 | KM14 | MB14 | |||
H315 | 2-5/8 | 2-7/16 | 2-1/2 | 65 | 75 | 98 | 55 | 15 | M75x2 | 0.83 | A315 | KM15 | MB15 |
H316 | 2-7/8 | 2-11/16 | 2-3/4 | 70 | 80 | 105 | 59 | 17 | M80x2 | 1 | A316 | KM16 | MB16 |
H317 | 2-15/16 | 3 | 75 | 85 | 110 | 63 | 18 | M85x2 | 1.2 | A317 | KM17 | MB17 | |
H318 | 3-1/8 | 3-3/16 | 3-1/4 | 80 | 90 | 120 | 65 | 18 | M90x2 | 1.35 | A318 | KM18 | MB18 |
H319 | 3-5/16 | 3-1/4 | 85 | 95 | 125 | 68 | 19 | M95x2 | 1.55 | A319 | KM19 | MB19 | |
H320 | 3-7/16 | 3-1/2 | 90 | 100 | 130 | 71 | 20 | M100x2 | 1.7 | A320 | KM20 | MB20 | |
H321 | 95 | 105 | 140 | 74 | 20 | M105x2 | 1.95 | A321 | KM21 | MB21 | |||
H322 | 3-15/16 | 4 | 100 | 110 | 145 | 77 | 21 | M110x2 | 2.2 | A322 | KM22 | MB22 |
Application:
1. Adapter sleeve is used tofix the conic aperture self-aligning ball bearing (self-aligning ball bearing, self-aligning roller bearing) on the non-bearing shoulder bearing. It is simply structured and its working is reliable. Easy to replace the bearing.
2, Widely applied in the lines of textile, light industry, metallurgy, belt convey and transmission equipment, etc.
