Home > Products > Ball Bearing > Cafe Racer Thrust Ball Bearing 51104
Cafe Racer Thrust Ball Bearing 51104
US$ 0.1 - 100
/ Piece
10 Pieces(Min. Order)
- shanghai or ningbo or qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Brand Name | 15 | Bore Size | 20, | |
| Outside Diameter | 35, | Model Number | 51104 | |
| Precision Rating | p0 p6 p5 p4 | Seals Type | open | |
| Number of Row | Single Row | Place of Origin | Shanghai, China |
Product Description
Specifications
KOYO 51104 ball bearing1.certification:CE/IAF/SGS
2.GMC supplier
3.more quality,lower prices
4.Offer free samples
Thrust ball bearings are classified into those with flat seats or aligning seats depending on the shape of the outer ring seat (housing washer). They can sustain axial loads but no radial loads. For Single-Direction Thrust Ball Bearings, pressed steel cages and machined brass cages are usually used The cages in Double- Direction Thrust Ball Bearings are the same as those in Single-Direction Thrust Ball Bearings of the same diameter series.
| Bearing NO. | I.D | O.D | W | Load Rating (KN) | Steel Ball Parameter | Max Speed | ||||||
| d | D | T | Dynamic | Static | NO. | Size | Grease | Oil | ||||
| mm inch | mm inch | mm inch | Ca | Coa | mm | r/min | r/min | |||||
| 51100 | 10 | 0.3937 | 24 | 0.94488 | 9 | 0.35433 | 10100 | 14000 | / | / | 6700 | 10000 |
| 51101 | 12 | 0.4724 | 26 | 1.02362 | 9 | 0.35433 | 10400 | 15400 | / | / | 6700 | 10000 |
| 51102 | 15 | 0.5906 | 28 | 1.10236 | 9 | 0.35433 | 10600 | 16800 | / | / | 6300 | 9500 |
| 51103 | 17 | 0.6693 | 30 | 1.1811 | 9 | 0.35433 | 11400 | 19500 | / | / | 6000 | 9000 |
| 51104 | 20 | 0.7874 | 35 | 1.37795 | 10 | 0.3937 | 15100 | 26600 | / | / | 5300 | 8000 |
| 51105 | 25 | 0.9843 | 42 | 1.65354 | 11 | 0.43307 | 19700 | 37000 | / | / | 4800 | 7100 |
| 51106 | 30 | 1.1811 | 47 | 1.85039 | 11 | 0.43307 | 20600 | 42000 | / | / | 4300 | 6700 |
| 51107 | 35 | 1.378 | 52 | 2.04724 | 12 | 0.47244 | 22100 | 49500 | / | / | 4000 | 6000 |
| 51108 | 40 | 1.5748 | 60 | 2.3622 | 13 | 0.51181 | 27100 | 63000 | / | / | 3600 | 5300 |
| 51109 | 45 | 1.7716 | 65 | 2.55905 | 14 | 0.55118 | 28100 | 69000 | / | / | 3400 | 5000 |
| 51110 | 50 | 1.9685 | 70 | 2.7559 | 14 | 0.55118 | 29000 | 75500 | / | / | 3200 | 4800 |
| 51111 | 55 | 2.16535 | 78 | 3.07086 | 16 | 0.62992 | 35000 | 93000 | / | / | 2800 | 4300 |
| 51112 | 60 | 2.3622 | 85 | 3.34645 | 17 | 0.66929 | 41500 | 113000 | / | / | 2600 | 4000 |
| 51113 | 65 | 2.55905 | 90 | 3.5433 | 18 | 0.70866 | 42000 | 117000 | / | / | 2400 | 3800 |
| 51114 | 70 | 2.7559 | 95 | 3.74015 | 18 | 0.70866 | 43500 | 127000 | / | / | 2400 | 3600 |
| 51115 | 75 | 2.95275 | 100 | 3.937 | 19 | 0.74803 | 43500 | 131000 | / | / | 2200 | 3400 |
| 51116 | 80 | 3.1496 | 105 | 4.13385 | 19 | 0.74803 | 45000 | 141000 | / | / | 2200 | 3400 |
| 51117 | 85 | 3.34645 | 110 | 4.3307 | 19 | 0.74803 | 46500 | 150000 | / | / | 2200 | 3200 |
| 51118 | 90 | 3.5433 | 120 | 4.7244 | 22 | 0.86614 | 60000 | 190000 | / | / | 1900 | 3000 |
| 51120 | 100 | 3.937 | 135 | 5.31495 | 25 | 0.98425 | 86000 | 268000 | / | / | 1700 | 2600 |
