Beam for sale
Characteristics:
1,Light Weight: the density of H20 Timber Beam is only 4.8-5.0 kg per meter, it is easy to deliver,dismantle and install.
2,High Tenacity: The H20 Timber Beam is not easy to break off because of fiber.
3,Good Proofing: The H20 Timber Beam is good at waterproofing, acidproof, alkaliproof, moth proofing.
4,Environment Friendly: The Timber Beam belongs to renewable resources, could be used many time.and without poison, no damage to health.
5,Good Straightness: The H20 Timber Beam in not easy to deform.
Specifications | |
Item |
LW-TB301 |
Wing Material |
Imported spruce solid wood, finger-jointed and glueing according to DIN 68140-1 |
Web Material |
Multilayer poplar plywood |
Head Protection |
Without head protection |
Glueing |
(PRF) Finger-jointed between wings and web pursuant to approval notice Z-9.1-146 |
Moisture Content |
less than 12% at the time of delivery |
Surface Protection |
The complete beam is waterproofed using a water-repellent color glaze |
Color |
Yellow or as customer's request |
Wing Size |
80x40mm |
Web Size |
30mm thickness |
Weight |
about 5kg/m |
Standard lengths |
2.45 / 2.90 / 3.30 / 3.90 / 4.90 / 5.90 m (Max.length:6.00m) |
Mechanical Specification |
Modulus of elasticity : E 11,000 N/mm2 |
Shear modulus : G 600 N/mm2 | |
Packing |
Pallet or in bulk |
Application |
Level formwork system, Vertical formwork system, Adjustable formwork system, Curve formwork system, Irregular formwork, etc. |
....
