USB3.0 Video capture device
Product feature:
l Specification : USB 3.0;
l H.264 video capture;
l Full HD 1080p60;
l Support Windows 8, NTSC / PAL;
l Plug and play, Circumscribed USB 3.0 Interface design, Suitable for laptop or desktop computer;
l Supply power through USB interface instead of additional power supply connection;
l Video input: HD-SDI ×1 / HDMI ×1 / YPbPr ×1 / DVI-D ×1 / S-Video×1 / Composite ×1/ RCAstereophonic ×1;
l Image compression format: H.264 (AVC High Profile @L4.1);
l Support dynamic image capture, AVI / MPEG-4 (CBR/VBR) format and single static capture;
l Support RTSP / HLS / RTMP Media Streaming Protocol, and support built-in streaming output;
l Support Continuous images capture at a high speed, capture1-100 pieces of picture continuously;
l Support Preview Window 2 size switch and full screen preview function;(2:1/1:1/full screen);
l Support NVIDIA CUDA Hardware Acceleration, Reduce the CPU load;
l Support light, contrast, chroma, saturation, and sharpness adjustment;
l Support video reservation, support once, everyday or each week video reservation schedule
l Support other application software;
l Adobe Flash Media Live Encoder 3.2,Edius 6.0,Expression Encoder 4.0,Ustream Producer 1.0.2,Windows Media Encoder 9.0,Skype 6.x;
l Support Internet streaming platform:,,;
Input | Mode | Resolution |
HD-SDI | HD | 1080p @24/25/30/50/60fps |
SD | 480p @50/60fps | |
S-Video | SD | 480i @25/30fps |
HDMI | PC | 800 × 600 |
1024 × 768 | ||
1280 × 960 | ||
1280 × 1024 | ||
1440 × 900 |
Note: Support HD-SDI digital signal input, unsupport SDI analog signal input;
HDCP protection signals is unsupported when HDMI is inputing;
Macrovision copy protect signals is unsupported when YPbPr is inputing.
System Requirements | |||||||||||||
|
Product list:
•USB Capture Card ×1
•YPbPr recombination Terminal cable x1
•Video recombination Terminal cable x1
•USB 3.0 connecting line ×1
•DVI to D-Sub adapter ×1
•Driver CD ×1
•Fast installation instructions x1
•Product/service warranty card x1
