Rare Earth Permanent Magnet

Rare Earth Permanent Magnet thumbnail-1
Rare Earth Permanent Magnet thumbnail-2
Rare Earth Permanent Magnet thumbnail-3
Rare Earth Permanent Magnet thumbnail-4
Rare Earth Permanent Magnet thumbnail-5
Rare Earth Permanent Magnet thumbnail-6
Rare Earth Permanent Magnet photo-1
Rare Earth Permanent Magnet photo-2
Rare Earth Permanent Magnet photo-3
Rare Earth Permanent Magnet photo-4
Rare Earth Permanent Magnet photo-5
Rare Earth Permanent Magnet photo-6
US$ 0.01 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
SDM
Model Number:
magnet
Contact Supplier Request Quote Chat Now
Hangzhou SDM Magnetics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name SDM
Model Number magnet
Type Permanent
Composite Rare Earth Magnet
Shape Other, cylider
Application Industrial Magnet

rare earth permanent grade mmm 100 mmm neodymium cylinder ndfeb magnet

Product Description



rare earth permanent magnet

rare earth permanent magnetrare earth permanent magnetrare earth permanent magnet

rare earth permanent magnetrare earth permanent magnetrare earth permanent magnet

 Grade Residual Induction (Br) Coercive Force (Hcb) Intrinsic coercive Force (Hcj) Max Energy Product (BH)max Max Working Temp.
T                   kGs kA/m kOe kA/m kOe Kj/m³ MGOe (°C)
N35 1.17-1.22 11.7-12.2 ≥ 868  ≥ 10.9  ≥ 955  ≥ 12 263-287 33-36 80
N38 1.22-1.25 12.2-12.5 ≥ 899  ≥ 11.3  ≥ 955  ≥ 12 287-310 36-39 80
N40 1.25-1.28 12.5-12.8 ≥ 907  ≥ 11.4  ≥ 955  ≥ 12 302-326 38-41 80
N42 1.28-1.32 12.8-13.2 ≥ 915  ≥ 11.5  ≥ 955  ≥ 12 318-342 40-43 80
N45 1.32-1.38 13.2-13.8 ≥ 923  ≥ 11.6  ≥ 955  ≥ 12 342-366 43-46 80
N48 1.38-1.42 13.8-14.2  ≥ 923  ≥ 11.6  ≥ 955  ≥ 12 366-390 46-49 80
N50 1.40-1.45 14.0-14.5  ≥ 796  ≥ 10  ≥ 876  ≥ 11 374-406 47-51 60
N52 1.43-1.48 14.3-14.8  ≥ 796  ≥ 10  ≥ 876  ≥ 11 390-422 49-53 60
N35M 1.17-1.22 11.7-12.2  ≥ 868  ≥ 10.9  ≥ 1114  ≥ 14 263-287 33-36 100
N38M 1.22-1.25 12.2-12.5  ≥ 899  ≥ 11.3  ≥ 1114  ≥ 14 287-310 36-39 100
N40M 1.25-1.28 12.5-12.8  ≥ 923  ≥ 11.6  ≥ 1114  ≥ 14 302-326 38-41 100
N42M 1.28-1.32 12.8-13.2  ≥ 955  ≥ 12  ≥ 1114  ≥ 14 318-342 40-43 100
N45M 1.32-1.38 13.2-13.8  ≥ 955  ≥ 12.5  ≥ 1114  ≥ 14 342-366 43-46 100
N48M 1.37-1.43 13.7-14.3  ≥ 1027  ≥ 12.9  ≥ 1114  ≥ 14 366-390 46-49 100
N50M 1.40-1.45 14.0-14.5  ≥ 1033  ≥ 13  ≥ 1114  ≥ 14 382-406 48-51 100
N35H 1.17-1.22 11.7-12.2  ≥ 868  ≥ 10.9   ≥ 1353  ≥ 17 263-287 33-36 120
N38H 1.22-1.25 12.2-12.5  ≥ 899  ≥ 11.3  ≥ 1353  ≥ 17 287-310 36-39 120
N40H 1.25-1.28 12.5-12.8  ≥ 923  ≥ 11.6  ≥ 1353  ≥ 17 302-326 38-41 120
N42H 1.28-1.32 12.8-13.2  ≥ 955  ≥ 12  ≥ 1353  ≥ 17 318-342 40-43 120
N45H 1.32-1.36 13.2-13.6  ≥ 963  ≥ 12.1  ≥ 1353  ≥ 17 326-358 43-46 120
N48H 1.37-1.43 13.7-14.3  ≥ 995 12.5  ≥ 1353  ≥ 17 366-390 46-49 120
N35SH 1.17-1.22 11.7-12.2  ≥ 876  ≥ 11  ≥ 1592  ≥ 20 263-287 33-36 150
N38SH 1.22-1.25 12.2-12.5  ≥ 907  ≥ 11.4  ≥ 1592  ≥ 20 287-310 36-39 150
N40SH 1.25-1.28 12.5-12.8  ≥ 939  ≥ 11.8  ≥ 1592  ≥ 20 302-326 38-41 150
N42SH 1.28-1.32 12.8-13.2  ≥ 987  ≥ 12.4  ≥ 1592  ≥ 20 318-342 40-43 150
N45SH 1.32-1.38 13.2-13.8  ≥ 1003  ≥ 12.6  ≥ 1592  ≥ 20 342-366 43-46 150
N28UH 1.04-108 10.4-10.8  ≥ 764  ≥ 9.6  ≥ 1990  ≥ 25 207-231 26-29 180
N30UH 1.08-1.13 10.8-11.3  ≥ 812  ≥ 10.2  ≥ 1990  ≥ 25 223-247 28-31 180
N33UH 1.13-1.17 11.3-11.7  ≥ 852  ≥ 10.7  ≥ 1990  ≥ 25 247-271 31-34 180
N35UH 1.17-1.22 11.7-12.2  ≥ 860  ≥ 10.8  ≥ 1990  ≥ 25 263-287 33-36 180
N38UH 1.22-1.25 12.2-12.5  ≥ 876  ≥ 11  ≥ 1990  ≥ 25 287-310 36-39 180
N40UH 1.25-1.28 12.5-12.8  ≥ 899  ≥ 11.3  ≥ 1990  ≥ 25 302-326 38-41 180
N42UH 1.28-1.32 12.8-13.2  ≥ 899  ≥ 11.3  ≥ 1990  ≥ 25 318-342 40-43 180
N28EH 1.04-1.08 10.4-10.8  ≥ 780  ≥ 9.8  ≥ 2388  ≥ 30 207-231 26-29 200
N30EH 1.08-1.13 10.8-11.3  ≥ 812  ≥ 10.2  ≥ 2388  ≥ 30 223-247 28-31 200
N33EH 1.13-1.17 11.3-11.7  ≥ 836  ≥ 10.5  ≥ 2388  ≥ 30 247-271 31-34 200
N35EH 1.17-1.22 11.7-12.2  ≥ 876  ≥ 11  ≥ 2388  ≥ 30 263-287 33-36 200
N38EH 1.22-1.25 12.2-12.5  ≥ 899  ≥ 11.3  ≥ 2388  ≥ 30 287-310 36-39 200
N40EH 1.25-1.28 12.5-12.8  ≥ 899  ≥ 11.3  ≥ 2388  ≥ 30 302-326 38-41 200
N28AH 1.04-1.08 10.4-10.8  ≥ 787  ≥ 9.9  ≥ 2624  ≥ 33 207-231 26-29 230
N30AH 1.08-1.13 10.8-11.3  ≥ 819 10.3  ≥ 2624  ≥ 33 223-247 28-31 230
N33AH 1.13-1.17 11.3-11.7  ≥ 843  ≥ 10.6  ≥ 2624  ≥ 33 247-271 31-34 230
N35AH 1.17-1.22 11.7-12.2  ≥ 876  ≥ 11  ≥ 2624  ≥ 33 263-287 33-36 230
N38AH 1.22-1.25 12.2-12.5  ≥ 899  ≥ 11.3  ≥ 2624  ≥ 33 287-310 36-39 230
Advantages



Custom  ndfeb magnet

1)High performance and High Working Temperature

rare earth permanent magnet

2)High Consistancy

rare earth permanent magnet

3)High Anti-Corrosion and Low Weight Loss

rare earth permanent magnet

rare earth permanent magnet

Company Information



Seniority and integrity.

Hangzhou SDM Magnetics Co.,Ltd established in 2004year,over 10 years experience in cable filed.“Quality”and “integrity”is the life of enterprise. After a long-term development, establish a good reputation in the market and among the customers.

Technology
supervise, technology and advanced services. We have the advanced manufacturing equipment and quality test equipment for each batch of product testing. Also, we can design and produce every single specification for every customer’s different requirement.

Factory

Our factory located in the Tonglu,Xiaoshan. Total about 2000 employees including 130 production workers,30QC and 20 engineers. The factory area is 17,000 m2.We have a complete industry chain. And we have our own raw material supply which decreased the procurement cost.

partners

We cooperate with the most famous global cable brand---Siemens Ltd Australia,GM, BMW, BENTLEY, REGAL BELOIT.

certificate

Our core competences:certificates of TS16949,ISO9001,ROHS

rare earth permanent magnet

Packaging & Shipping



rare earth permanent magnet

round magnet Packing and Shipping



a: the weight is under 40Kg,we will choose FedEx,DHL or UPS with shielding box for you;

b: the weight is over 100Kg,we will choose shipping for you;

c: the weight is between 40Kg-100Kg, per you request;



rare earth permanent magnet



rare earth permanent magnet

FAQ



Round magnet

1:How long will you give me the reply?

we will contact you in 12 hours as soon as we can.

2:Could I get samples?

Yes,we have materials in stock to help you to get the samples as soon as we can.

3:How about the quality of the magnets?

We have the certification of ISO,TS and ROSH,we could send the certification test of our company to you.

4:How is the price?

As we believe the quality is the most important,we will provide the best quality magnet we can with reasonable price.

5:Could you provide me the shortest lead time?

We have materials in our stock,if you really need,you can tell us and we will try our best to satisfy you.

6:Could I visit your factory?

Of course,if you need we will help you to visit our factory.

7:If I have paid,when will you help me to produce?

When we have received the money in our account,we will give you the receipt and arrange to produce immediately.
