360 degrees pan tilt zoom sd video conference camera with ceiling amount
18* Optical 550 TVL PTZ camera video conferencing studio (KT-D848)
18* Optical 550 TVL PTZ camera video conferencing studio (KT-D848)
Item No. |
KT-D848 |
Image Sensor |
SONY 1/4 Exwave HAD CCD |
Effective Pixel |
752 (H) * 582 (V) |
Signal System |
NTSC/PAL |
Horizontal Resolution |
550 TVL |
Synchronization |
Internal & External |
Lens |
18* Optical, F=4.1mm(tele)~73.8mm(wide), F1.4~F3.0 |
Angle of View (H) |
48°(wide-angle)~2.8°(far-end) |
Min. object distance |
290mm(wide-angle)~800mm(tel-end) |
Minimum Illumination |
0.4lux (F1.4, 50IRE) |
Auto exposure |
Auto/Manual/AE priority/Exposure compensation/Backlight compensation |
Shutter Speed |
1/3~1/10000S,22 shelves |
Gain |
Auto/Manual (-3 ~ +28dB, 16 steps) |
White Balance |
Auto/Indoor/Outdoor/One push WB/Manual WB |
S/N Ratio |
more than 50dB |
Pan/Tilt |
Pan: +/- 355° (max. speed: 80°/s) Tilt: -30° to + 90° (max. speed: 60°/s) |
Preset Position |
9 by remote commander, 256 by keyboard controller |
Picture effect |
E-Flip, Invert, Mirror |
Analog Output |
VIDEO and S-VIDEO VBS 1.0VP-P |
Camera Control |
RS-232C(8-pin DIN)/(VISCA)/RS-422(9-pin) (VISCA) |
Baud rate |
9600bps, 38400bps |
Power |
10.8V~13.2V |
Operating Temperature |
0℃~50℃ |
Storage Temperature |
-20℃~+60℃ |
Consumption |
12W |
Dimensions |
(L)153*(W)134*(H)153mm |
Weight |
1200g |
Color |
black |
18* Optical 550 TVL PTZ camera video conferencing studio (KT-D848)
Q&A
1)What is your minimum order quantity?
-- one full container at least 5sets each model. Sample order is acceptable.
2)Do you have products in stock?
--Some types of video conference camera have, and haven’t.It depend your order module.
3)What is your delivery terms?
--FOB to your country by DHL,Fedex through air.
Payment terms is T/T in advance, Western Union, Paypal ect.
4)When will you ship my order?
--Ordinary,once we get confirmation for payment,we will ship order within 1-3days.
5)The video confence camera doesn’t have the interface I need, what should I do?
--Yes, it might cannot meet your requirement. However, Talk to our sale, the interface we can add to conferencing camera with charging extra fees. We promised : All your need we will try our best to satified you.
6)Can I install the conference camera by myself?
--Of course,the conferencing camera is flexible to install. We supplied camera accompanied with DV 12V power adapter, IR controller, braket, operation menu, RS-232 cable and YPBPR cable.You can install by user manual or you can contact us in need.
7)How about warranty?
--Generally, modules for 1 year, and conference camera for 2 years.
Life-time provide technical consulting.
KATO VISION CO., LIMITED
Phone: +86-755-89500973
Skype: Jenny Kato
TradeManager: cn1511526172
Website: /
Address:4/F, Block B, Dexinchang Industrial Park, Qingxiang Rd., Longhua district, Shenzhen 518109, China
