Y32 Four Column Hydraulic Press

Y32 Four Column Hydraulic Press thumbnail-1
Y32 Four Column Hydraulic Press photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
CNC
Power Source:
Mechanical
Contact Supplier Request Quote Chat Now
Huzhou Xinke Forging Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not CNC
Power Source Mechanical
Place of Origin Zhejiang, China
Brand Name xinke
Model Number Y32
Voltage 380V
Power(W) 5.5-90kw
Weight 1.5-76t
Dimension(L*W*H) see design
Certification iso9001-2000
Warranty for one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Y32 Series Four Column Hydraulic Press
1, intuitive movement
2, high reliability, durability
3, small hydraulic impact

Specifications



            Y32 Series Four Column Hydraulic Press 1, intuitive movement 2, high reliability, durability 3, small hydraulic impact



Y32 Four Column Hydraulic PressName: Y32 Four Column Hydraulic Press

Characteristics of Y32 Four Column Hydraulic Press:

1, Computer optimized design,3-beam&4-column compact structure; 2, Cartridge Valve Integrated System equipped in hydraulic control system with high reliability, durability, small hydraulic impact and minimizing hydraulic impact design;3, Independent electrical control system with reliability, intuitive movement and convenient amendment ;4, Adopting Button common control; 5, Preset Stroke Forming or Preset Pressure Forming process can be selected

Applications of Y32 Four Column Hydraulic Press:

Drawing, bending, flanging, cold extruding, blanking processes for metal materials; Adjusting, press-in and forming processes for powder and abrasive products, plastic and insulation materials

Technical Specifications  of Y32Four Column Hydraulic Press

Item             type Unit Y32-40 Y32-63 Y32-100 Y32-125 Y32-200 Y32-315 Y32-400 Y32-500 Y32-630 Y32-800 Y32-1000 Y32-1250
Nominal Pressure kN 400 630 1000 1250 2000 3150 4000 5000 6300 8000 10000 12500
Ejecting Force kN 100 160 630 630 800 800 800 1000 1000 1250 2000 2000
Knock-out Force kN 150 125 160 180 360 450 345 570 850 720 1600 1200
The Max. Pressure of Working Fluid MPa 25 25 25 25 25 25 25 25 25 25 25 25
The Max. Stroke of Slider mm 320 500 630 630 710 800 800 900 1000 1000 1000 1000
The Max. Stroke of Ejector mm 150 160 200 200 250 300 300 300 300 350 450 450
The Max. Opening Height mm 520 800 900 900 1120 1250 1250 1500 1600 1600 1600 1800
Speed of Slider Descend mm/s 55 115 250 220 160 120 180 150 120 150 150 250
working mm/s 10-35 10-22 12-40 9-31 7-24 8-20 10-24 10-24 8-18 8-15 5-12 8-15
Return mm/s 105 105 200 180 120 120 250 180 125 145 75 140
             Speed of Ejector Ejecting mm/s 170 90 120 60 60 75 120 65 65 50 60 45
Return mm/s 450 220 125 125 120 150 120 135 135 120 120 120
               Active Area of Working Table(E×D) Left-Right mm 450 570 710 710 930 1260 1300 1400 1880 1880 2000 2500
Front-Back mm 400 500 630 630 900 1200 1300 1400 1600 1600 1800 2000
Overall Dimension Front-Back mm 1230 1850 2100 2200 2350 2840 3600 3840 5230 5550 5946 8000
                           The Height between Working Table and Ground Left-Right mm 1234 1855 1880 1880 2000 2000 2600 2800 2800 2600 3135 3400
Front-Back mm 1115 2900 3260 3260 3520 4175 4800 4960 5257 5630 5614 7600
Height above the Ground mm 870 800 860 860 550 650 710 500 500
Electric Motor Power kW 5.5 5.5 11 11 15 22 30 44 44 60 74 90
Weight of Machine t 1.5 2.7 4 41 10 13 17 21 33 43 52 76

Options of Y32 Four Column Hydraulic Press:

Cutting Dampening system; Oil heating/cooling unit; Displacement sensor; Industrial touching screen monitor; PLC programmable controller; Floating guide-way and rolling bracket for die exchange; Working area lighting; Quick die clamping device; Light curtain safety device

Products of Y32 Four Column Hydraulic Press:
