China Magnesium Board Factory Supplier Compact Laminate Mgo Board

China Magnesium Board Factory Supplier Compact Laminate Mgo Board thumbnail-1
China Magnesium Board Factory Supplier Compact Laminate Mgo Board thumbnail-2
China Magnesium Board Factory Supplier Compact Laminate Mgo Board thumbnail-3
China Magnesium Board Factory Supplier Compact Laminate Mgo Board thumbnail-4
China Magnesium Board Factory Supplier Compact Laminate Mgo Board thumbnail-5
China Magnesium Board Factory Supplier Compact Laminate Mgo Board thumbnail-6
China Magnesium Board Factory Supplier Compact Laminate Mgo Board photo-1
China Magnesium Board Factory Supplier Compact Laminate Mgo Board photo-2
China Magnesium Board Factory Supplier Compact Laminate Mgo Board photo-3
China Magnesium Board Factory Supplier Compact Laminate Mgo Board photo-4
China Magnesium Board Factory Supplier Compact Laminate Mgo Board photo-5
China Magnesium Board Factory Supplier Compact Laminate Mgo Board photo-6
US$ 4 - 20 MOQ: 900 Sheets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Chinsunboard
Model Number:
magnesium oxide board
Contact Supplier Request Quote Chat Now
Yuyao Chinsun Building Material Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Chinsunboard
Model Number magnesium oxide board

China mgo board supplier compact laminate mgo board

Magnesium Oxide Board Introduction

Mgo board is a kind of new green and fireproof building material which is used in place of traditional gypsum drywall as partition wall and ceiling covering material and sheathing.

Mgo boards could be used anywhere Gypsum boards or dry walls could be used, such as wall board, backer board,underlayment, siding etc. It's do have many advantages over gypsum boards or dry walls which make them the material of choice for new constructions and renovations.

China Magnesium Board factory supplier compact laminate mgo board

  Specication and Product Date
 Standard Size  1220mmx2440mm or 1200mmx2400mm
 Max Width  1220mm
 Max Length  3050mm
 Thickness  3mm-25mm
 Density

 0.8-1.2g/cm³

(Normal standard is 0.9-1.0g/cm³)
 Basic Color  White or Grey
 Surface  Thin slurry surface
 Moisture Content  ≤10%
 Water Absorbing  ≤40%
 Bending Strength  12-25Mpa
 Fire Resistance  Incombustibility Class A1
 Thermal Conductivity  0.19W/(m·K)
 The rate of deformation  when pick up the moisture:0.26%
 The shrinking rate  when heated:1.0%
 Security  100% does not include asbestos,formaldehyde,benzene
 Radioactivity  Not limited by the scope of application



Edge:Square Edge/ Tapered Edge/ Chamfered Edge/ Tongue&Groove Edge



China Magnesium Board factory supplier compact laminate mgo board

  Raw Material and structure

 High Quality Magnesium oxide(MGO), Magnesium sulfate, Perlite, Wood dust, Fiberglass mesh, Non-woven cloth etc.

China Magnesium Board factory supplier compact laminate mgo board

China Magnesium Board factory supplier compact laminate mgo board

Remark:Customers can also customize according to their own requirement,such as add one or two layers of fiber glass net reinforcing layer to increased the strength of the panel.
We also can produce Chloridion Free Mgo board,further information please feel free to contact us!

  Production

  China Magnesium Board factory supplier compact laminate mgo board

Packaging & Shipping

China Magnesium Board factory supplier compact laminate mgo board

China Magnesium Board factory supplier compact laminate mgo board




Size (MM) Thickness (MM) Weight (KGS) Loading Quantity Per 20GP(PCS)
1220*2440 3 9 1800
1220*2440 6 18 900
1220*2440 8 24 690
1220*2440 9 27 600
1220*2440 10 30 540
1220*2440 12 36 450
1220*2440 15 45 360
1220*2440 18 48

300



  Company Information

    Yuyao Chinsun Building Material Factory based in China and has been established for over 15 years and is one of the biggest manufacturers of fiber cement boards ,magnesium oxide boards ,calcium silicate boards under the trademark Chinsunboard.

    We are providing various of building materials which can be used for interior wall partition,exterior façade,ceiling and flooring etc.All of the products are 100% without asbestos and with CE marking.

    We control our quality and stability of products strictly with ISO9001 International Quality Control System and provide professional solution for various requirements form different customers.

China Magnesium Board factory supplier compact laminate mgo board

Why Choose Mgo Board

  WHY so many customers choose Our mgo board?
                                                     Choose Chinsun board , choose green healthy life



1)Fireproof capability:the fireproof capability can be reached 2-3 hours, and it’s no combustion at 800ºC and no flame out at 1200ºC.

2)Sound and heat insulation:the Sound insulation will be more than 45db (depend on the structure), and it has a great performance on heat insulation

3)Shockproof:Fiberglass mesh inside the boards is designed to absorb shocks. It results in a shockproof and bend-proof board to increase durability.

4)Health concerns:MgO boards are Asbestos free,non toxicity and formaldehyde free.

5)Other advantages: Lighter,more flexible and stable than tradition sheeting systems;Time and material saving-dramatically reducitng construction costs;Environmentally friendly.

China Magnesium Board factory supplier compact laminate mgo board

Certification and Test Report
  China Magnesium Board factory supplier compact laminate mgo board
FAQ

1. Q: Are factory tours available?

    A: Yes, factory tours are available. We look forward to walking interested individuals through our manufacturing facility and introducing you to our unique product.

2. Q: Can load different size in one container?

    A: Yes, We will help you to check the loading quantity for each size

3. Q: Are you factory or trading company?

     A:We are one factory who has speicialized in the fireproofing materials for 20 years with ISO9001-2008, CE and other certificates.



4. Q: Do you need sample fee?

     A:We prepare the sample for free if you really need the samples to test, and you just pay the courrier fees.

5. Q: How to make order if I am satisfied with your products?

    A:PLease send us your purchase information by email or fax, it's wise for you to ask the PI from us, pls note the following things in your requirments:

(1) Product information,- Quatity, specification, type, color, packing, and other requirements you want to get.

(2) Delivery time required:

(3) Shipping documents, we should get to know your information-company name, address, phone/fax,your destination port.

(4) If you have some forwarders in China,pls inform us your forwarders contact details after the goods have been ready.

Please feel free to contact us if you need further information of our product introduction and technical properties,etc.
