Friction Press

Specifications

Friction Press
1,with high precious and durability
2,simple controlling
3, reliable performance

Name:    Friction Press



Characteristics of  Friction Press

1,Gantry or Four-column style based on Computer Optimizing Structure Design with high precious and durability.

2,Latest Closed-loop ratio control technology with digital display, position, pressure and speed setting,

3,Adopted in Inverter Control System with simple controlling, reliable performance and also reach to special SMC forming process.

4,Intelligent Temperature Control System. The precision can reach to ±5°C and Monitoring working conditions for heating elements of hotplate

5, Industrial Touching Screen Monitor and Communication module. Production control room uniform class and monitoring production process and statistics

6, 630T Gantry Hydraulic Press is with exhaust system and Multilayer mold temperature control system, featuring high reliability and high quality



 Apllications of  Friction Press:

 With the latest Frequency Conversion Control Technology, digital control the speed, pressure, position, pre-press and pressing process. The presses are will suitable for high quality production of various thermo setting friction products. Widely used on making brake pad of automobile industry



Technical Specifications of  Friction Press

Items             Type		Unit	Y79-100	Y79-200	Y79-315	Y79-500	Y79-630
Nominal Pressure		kN	1000	2000	3150	5000	6300
Knock-out Force		kN	160	360	450	760	650
Ejecting Force		kN	300	400	630	630	630
Ejection Stroke		kN	200	250	300	300	300
The Max. Working Pressure of Fluid		MPa	25	25	25	25	25
Opening Height		mm	900	1120	1250	1500	1500
Slider Stroke		mm	600	710	800	900	800
Size of Working Table	Left-Right	mm	720	930	1250	1400	1300
	Front-Back	mm	630	900	1200	1400	900
Slider Speed	Idle Descend	mm/s	120	120	160	160	120
	Working	mm/s	6-15	7-18	6-15	4-11	2-5
	Exhausting	mm/s	3-5	3-5	3-5	3-5	3-5
	Return	mm/s	90	100	100	70	60
	Ejecting	mm/s	50	90	90	95	90
Configuration Power		Kw	7.5	15	22	22	15
Piston Pump		YCY	25	63	80	2*63
Structure			Four-Column	Four-Column	Four-Column	Four-Column	Gantry-Style





The options of   Friction Press :

Multilayer Frame; Mould heating system; Light curtain safety device; Intelligent Temperature Control System
