Remote Advertisement Management Free WiFi Advertising Device

Product Parameter

Contents

Hardware

Processor

ARM 1GHz

SDram

DDR II 1Gbite

Built-in flash

512MB built-in

Extended memory

External 8GB

Connection

Connection amount

Support 50 users to play videos, 200 users to connect

Network connection

LAN,3G,WIFI

Wi-Fi

Frequency range

2.4G(ISM frequency range)

Modulation system

OFDM: BPSK, QPSK, 16 QAM, 64QAM

DSSS: DBPSK, DQPSK, CCK

Working mode

AP mode,Station mode,

Speed supported

11B rate:1,2,4,6,9,11Mbps;

11G rate:6,9,12,18,24,36,48,54Mbps;

11N rate:MCS0-6.5,MCS1-13,MCS2-19.5,

MCS3-26,MCS4-39,MCS5-52,MCS6-58.5,MCS7-65

Frequency range

scanning

Support site scanning and communication channel detecting,

signal real-time status display

Radio frequency

Radio-frequence power

20dBm±2dBm,

Radio-frequency band

Support 5,10,20,HT40MHz

Sensitivity

-62dBm@150Mbps ,-65dBm@128Mbps ,-69dBm@78Mbps ,

-72dBm@54Mbps,-74dBm@48Mbps,-84dBm@12Mbps,-

90dBm@6Mbps,-95dBm@1Mbps

Safety

Encryption type

WPA

Safety management

Client-side isolation, hidden SSID,VLAN,VMSSID

ACL access strategy

ACL client-side MAC address filtering

Network

management

Supervisor mode

WEB,PC,Telnet configuration management

Upgrading and backups

Support remote online firmware upgrading;

configuration file backups/ importing

Reboot function

Support remote software/ hardware reboot, Ping Watchdog

Users

management

Bandwidth control

Client IP-based or MAC Bandwidth control

Interface

management

Ethernet interface

Standard: Gigabit Ethernet adaptable network interface

Antenna interface

Two external N-Female antenna ports

Electrical

property

Power source

DC 12V, 3A

Max power consumption

6W

Physical

property

Size

Primary device shell size: 21*16.5*4cm

Weight

Primary gross weight: 0.4kg

Product shell

ABS, waterproof box( optional), rust-proof, sun block

Environmental

characteristics

Operation temperature

-20℃ to 70℃, Storage temperature: -40℃ to 80℃

Operating humidity

10% to 90%RH non-condensing; Storage humidity:

5% to 90%RH non-condensing;

Waterproof grade

Waterproof box optional

Lightning protection

grade

Built-in power supply and reticle lightning protection module,

IEC61000-4-5

Accessories

Antenna

7dBi omni antenna, 14DBi directional antenna(optional)

Module accessories

Others

Power adapter, battery pack(optional)
