Web-based software WiFi Marketing Equipment , WiFi Advertising Product
Wi-Fi Marketing is a new trend of mobile phone marketing because it allows your business to send adverts and messages freely to people with iPhones, Blackberrys and android phones. These customers may not have access to Bluetooth but would certainly want to take advantage of using a Free Wi-Fi connection. With most people using their phones to access the Internet, the Wi-Fi Marketing service will help your business reach out to those people to advertise your latest special offers.
Compatible with 100% of Smartphone, (Iphone, Blackberry, HTC, Samsung, android phone...)
Compatible with 100% of laptop & Ipad with Wi-Fi
Push advertising contents to smartphone & laptop users
Approach more potential customers
Stand alone working, no need PC
Remote webserver management
Easy operation & stand alone work
Unlimited Advertising contents
Adwifi device set-up
Step 1: power on the device and connect the device to Internet by ethernet cable or 3G/4G.
Step 2: Upload the media content to device through our free software.
Mobile phone operational processure
Step 1: Turn on "WiFi" of mobile phone and connect the wifi of Adwifi device .
Step 2: Refresh the browser to redirect to media content.
Step 3: visit Internet freely
Web-based software to upload media content and control the device remotely
Specifications
Product Parameter |
Contents |
|
|
Hardware |
Processor |
MIPS: 24kec 580Mhz |
SDram |
DDR II 128MB |
|
Built-in flash |
32MB built-in |
|
Storage |
8GB |
|
|
Connection |
Connection amount |
60 |
Network connection |
LAN, 3G USB dongle |
|
Wi-Fi |
Frequency range |
2.4G(ISM frequency range) |
Modulation system |
OFDM: BPSK, QPSK, 16 QAM, 64QAM DSSS: DBPSK, DQPSK, CCK |
|
Work mode |
AP mode,Station mode, |
|
Speed supported |
11B rate:1,2,4,6,9,11Mbps; 11G rate:6,9,12,18,24,36,48,54Mbps; 11N rate:MCS0-6.5,MCS1-13,MCS2-19.5, MCS3-26,MCS4-39,MCS5-52,MCS6-58.5,MCS7-65 |
|
|
Frequency range scanning |
Support site scanning and communication channel detecting, signal real-time status display |
|
|
Radio frequency |
Radio-frequence power |
20dBm±2dBm, |
Radio-frequency band |
Support 5,10,20,HT40MHz |
|
Sensitivity |
-62dBm@150Mbps ,-65dBm@128Mbps ,-69dBm@78Mbps , -72dBm@54Mbps,-74dBm@48Mbps,-84dBm@12Mbps,- 90dBm@6Mbps,-95dBm@1Mbps |
|
|
Safety |
Encryption type |
WPA/WPA2 |
Safety management |
Client-side isolation, hidden SSID,VLAN,VMSSID |
|
ACL access strategy |
ACL client-side MAC address filtering |
|
|
Network management |
Supervisor mode |
WEB,PC,Telnet configuration management |
Upgrading and backups |
Support remote online firmware upgrading; configuration file backups/ importing |
|
Reboot function |
Support remote software/ hardware reboot, Ping Watchdog |
|
|
Users management |
Bandwidth control |
Client IP-based or MAC Bandwidth control |
|
Interface management |
Ethernet interface |
Standard: Gigabit Ethernet adaptable network interface |
Antenna interface |
One external N-Female antenna port |
|
|
Electrical property |
Power source |
DC 12V, 1A |
Max power consumption |
3W |
|
|
Physical property |
Size |
Primary device shell size: 8.5*10*2.5cm |
Weight |
Primary gross weight: 0.2kg |
|
Product shell |
Metal, rust-proof, sun block |
|
|
Environmental characteristics |
Operation temperature |
-20℃ to 70℃, Storage temperature: -40℃ to 80℃ |
Operating humidity |
10% to 90%RH non-condensing; Storage humidity: 5% to 90%RH non-condensing; |
|
Waterproof grade |
Waterproof box optional |
|
|
Lightning protection grade |
Built-in power supply and reticle lightning protection module, IEC61000-4-5 |
|
Accessories |
Antenna |
5dBi omni antenna, 7dBi omni or14DBi directional antenna(optional) |
Module accessories |
|
|
Others |
Power adapter, car charger and battery(optional) |
|
Advantages
Support more than 60 concurrent users
Interactive advertising communication with users
Unlimited advertising contents
Bandwidth limit
Compatible with all WiFi-enabled Smart phones, including iPhone, Blackberry, Samsung, HTC, etc
Compatible with all WiFi-enabled laptops, including Ipad.
Advertising contents include picture, animation, audio, video, website, etc,
Support php and html webpages
Support online advertising and offline advertising
24/7/365 autonomous working
Friendly Web-based software, easy to operate
Easy to understand and set up
Real-time statistics report, device operator can access the statistics report of users.
Remote management, device operator can log in the software wherever to
Manage all the devices remotely.
Build your own special advertising webpage
Adjust image size according to the cellphone screen
Work modes
1. Push Advertisement
1) Upload advertising contents onto Ad-WiFi
2) End users connect Ad-WiFi via Wi-Fi
3) Ad-WiFi pushes advertising contents on end users
4) End users need to read all advertising contents
5) End users connect internet freely
2. Redirect to advertising website
1) Configure advertising website redirected
2) End users connect Ad-WiFi via Wi-Fi
3) Ad-WiFi redirects browser to an advertising website
4) End users need to stay at the advertising website within redirect time
5) After Redirect time, end users can connect internet freely
3. Redirect to intranet advertising website
1) Upload a complete advertising website onto Ad-WiFi
2) End users connect Ad-WiFi via Wi-Fi
3) Ad-WiFi redirects browser to the intranet advertising website
4) End user visit advertising website
Company Information
As a specialized manufacturer and exporter of Bluetooth and wifi marketing products, our company has had business connections with clients from over 60 countries. We aim at providing our customers with high-quality products and perfect after-sales services. Sincerely hope to establish a lasting friendly business relationship with your esteemed company.
Our Service
Quickly shipment |
Quickly and professional technical support |
Free firmware upgrading |
One year Warranty |
