Specifications
Capsule Filling Machine, laboratory test, plant health products and other units of the capsules, the fit, locking.
FG400 Medical Capsule Filling Machine
Characteristics:
It is a new product which has been researched into and developed according to the capsule liquid filling and shrink fitting. It is a combined conveyor system. It is composed of capsule arranger (cap and body), shrink fitting plate, fore shafting machine. It completes the capsule cap arranging, stock catching, powder feeding. It locks the capsules according to the stipulated length.
Use: it is used for the shrink fitting of capsule cap and body, medical powder filling.
Features: low price, easy operation, convenient repair and maintenance, low power loss, high production efficiency, one machine multi-purpose etc.
Main Technical Specifications:
Suitable capsule: 00#-4#
Mould hole quantity: 255 grain
Voltage: 220V
Power: 0.3kw
Main Technical Specifications::
Power | 1200/MIN |
Power Supply | Arrange Machine AC220V 50Hz |
Lock Gob Machine AC380V 220V(Customer could choose it) | |
Consume Power | 470V |
A whole set | 1)Cap, Body Arrange Machine |
2)Lock Gob Machine(Beforehand lock )a set | |
3) With a corresponding set of plywood | |
Outer size | 1000×400×1200mm(Arrange Machine) |
590*×520×780mm(Lock Gob Machine) | |
Weight | 250Kg |
Output: 1min/plate
Overall size: 1140×570×1050mm
