Product Description
Feature |
Item |
High resolution for beauty shop 8.8inch lcd videowall commercial lcd videowall original panel with controller |
|
Characteristics |
Size |
8.8 inch |
Resolution |
480(Horizontal)*1920(Vertical) |
|
Interface |
MIPI |
|
Connect type |
Connector |
|
Color Depth |
16.7M |
|
Technology type |
a-Si |
|
Display Spec. Pixel pitch (mm) |
0.05075(H)×RGBx0.15225(V) |
|
Pixel Configuration |
R.G.B. Vertical Stripe |
|
Display Mode |
Normally Black |
|
Driver IC |
ILI6480 |
|
Surface Treatment |
3H |
|
Viewing Direction |
ALL |
|
|
Mechanical |
LCM (W x H x D) (mm) |
229.66*67.5*3.5 |
Active Area(mm) |
216.96*54.24 |
|
With /Without TSP |
Without |
|
Weight (g) |
TBD |
|
Luminace |
600nits |
Products Drawing:
CDTech Company
CDTech Products Pictures
| P/N | Size | Resolution | P/N | Size | Resolution |
| S032HV04 | 3.2" | 320*480 | S035VR14-T | 3.5" | 480*640 |
| S035Q01 | 3.5" | 320*240 | S035HV09 | 3.5" | 320*480 |
| S035Q01-T | 3.5" | 320*240 | S035HV09H | 3.5" | 320*480 |
| S035Q03-T | 3.5" | 320*240 | S035HV12 | 3.5" | 320*480 |
| S035Q08-T | 3.5" | 320*240 | S035HV13 | 3.5" | 320*480 |
| S035Q09 | 3.5" | 320*240 | S035HV13H | 3.5" | 320*480 |
| S035Q09-CTP | 3.5" | 320*240 | S039WQ01 | 3.9" | 480*128 |
| S035Q13-T | 3.5" | 320*240 | S040WV04 | 3.95" | 480*800 |
| S035Q24 | 3.5" | 320*240 | S042WQ01 | 4.2" | 240*432 |
| S035LQNC111 | 3.5" | 320*240 | S043WQ02 | 4.3” | 480*272 |
| S035LQNC111-CT | 3.5" | 320*240 | S043WQ07 | 4.3” | 480*272 |
| S035LQNC211 | 3.5" | 320*240 | S043WQ08 | 4.3” | 480*272 |
| S035LQNC116 | 3.5" | 320*240 | S043WQ09 | 4.3” | 480*272 |
| S035V01 | 3.5" | 480*640 | S043WQ018HB | 4.3” | 480*272 |
| S035V01-T | 3.5" | 480*640 | S043WQ15 | 4.3” | 480*272 |
| S035V03 | 3.5" | 480*640 | S043WQ21 | 4.3” | 480*272 |
| S035V03-T | 3.5" | 480*640 | S043WQ24 | 4.3” | 480*272 |
| S035V04 | 3.5" | 480*640 | S043WQ24H | 4.3” | 480*272 |
| S035V04-T | 3.5" | 480*640 | S043WQ26H | 4.3” | 480*272 |
| S035VR10 | 3.5" | 480*640 | S043WQ26H-CT6 | 4.3” | 480*272 |
| S035VR10-T | 3.5" | 480*640 | S043WQ28 | 4.3” | 480*272 |
| P/N | Size | Resolution | P/N | Size | Resolution |
| S043WQ36H | 4.3” | 480*272 | S050WV43-CT5 | 5.0" | 800*480 |
| S043WQ40H | 4.3” | 480*272 | S056V01 | 5.6" | 640*480 |
| S043WQ49 | 4.3” | 480*272 | S057Q01 | 5.7" | 320*240 |
| S043WQ55 | 4.3” | 480*272 | ma | 5.7" | 640*480 |
| S043WQ56 | 4.3” | 480*272 | S057V02 | 5.7" | 640*480 |
| S043WQ56H | 4.3” | 480*272 | S057V03 | 5.7" | 640*480 |
| S043WQ56HS | 4.3” | 480*272 | S058WV01 | 5.8" | 800*320 |
| S043WV07 | 4.3” | 800*480 | S060FW03 | 6.0" | 480*854 |
| S046WV01 | 4.6" | 800*320 | S065WV01 | 6.5" | 800*320 |
| S046WV02 | 4.6" | 800*320 | S065WV02 | 6.5" | 800*320 |
| S046WV03 | 4.6" | 800*320 | S070WV20 | 7.0" | 800*480 |
| S050WQ06 | 5.0" | 480*272 | S070WV83 V.1 | 7.0" | 800*480 |
| S050WQ06-T | 5.0" | 480*272 | S070WV83 V2.0 | 7.0" | 800*480 |
| S050WQ06-CT | 5.0" | 480*272 | S070WV84 | 7.0" | 800*480 |
| S050WQ07 | 5.0" | 480*272 | S070WV85-CT8 | 7.0" | 800*480 |
| S050WV02 | 5.0" | 800*480 | S070WV92 | 7.0" | 800*480 |
| S050WV06 | 5.0" | 800*480 | S070WV94 | 7.0" | 800*480 |
| S050WV07 | 5.0" | 800*480 | S070WV94H | 7.0" | 800*480 |
| S050WV43 | 5.0" | 800*480 | S070WV95/97 | 7.0" | 800*480 |
| S050WV44 | 5.0" | 800*480 | S070WV98 | 7.0" | 800*480 |
| S050WV44H | 5.0" | 800*480 | S070WV101 | 7.0" | 800*480 |
| S050WV43-T | 5.0" | 800*480 |
| P/N | Size | Resolution | P/N | Size | Resolution |
| S070WS03 | 7.0" | 1024*600 | S101WS09 | 10.1 | 1024*600 |
| S070WS08 | 7.0" | 1024*600 | S101WX06 | 10.1 | 1280*800 |
| S070WS12 | 7.0" | 1024*600 | S101FH01 | 10.1 | 1280*800 |
| S070WS14 | 7.0" | 1024*600 | CDT101PUW1-A00/S101WU01 | 10.1 | 1920*1200 |
| S070WX02 | 7.0" | 800*1280 | S091WX02 | 10.1 | 1920*480 |
| S070WU01 | 7.0" | 1200x1920 | S104V01 | 10.4" | 800*600 |
| S072WX01 | 7.2 | 1280*384 | S104SX01 | 10.4" | 800*600 |
| S080SV01 | 8.0" | 800*600 | S104SX02 | 10.4" | 800*600 |
| S080SV03H | 8.0" | 800*600 | G104VN01 V1 | 10.4" | 640*480 |
| S080SV04H-L | 8.0" | 800*600 | S104XG01 | 10.4" | 1024*768 |
| S080SV05H | 8.0" | 800*600 | S104XG02 | 10.4" | 1024*768 |
| S080XG04 | 8.0" | 1024*768 | S104SV05H | 10.4" | 800*600 |
| S080XG04H V2 | 8.0" | 1024*768 | S088WX03 | 10.8 | 1280*320 |
| S072WX02 | 8.2 | 1280*384 | S088WU02 | 11.8 | 1920*480 |
| S088WX01 | 8.8 | 1280*320 | S121SDS01 | 12.1" | 800*600 |
| S090WV02 | 9.0" | 800*480 | S121WX03 | 12.1" | 1280*800 |
| S091WX01 | 9.1 | 1920*480 | S123WU01 | 12.3" | 1920*720 |
| S072WX03 | 9.2 | 1280*384 | S150XG01 | 15.0" | 1024*768 |
| S088WX02 | 9.8 | 1280*320 | S170XG01 | 17" | 1024*768 |
| S101WS07 | 10.1 | 1024*600 | S190XG01 | 19" | 1024*768 |
| S101WS08 | 10.1 | 1024*600 | M220ZGE-L20 | 22" | 1680*1050 |
