High quality 3.5 inch TFT LCD Module display with 480*640 resolution,RGB/SPI/MCU interface
- 1000 Piece / Pieces per Month
- HK
- negative segment character running machine lcd display,practical STN,blue backlight, fitness equipment
- digital fire alarm installation module display, HTN segment display with blue led lcd panel
- negative autoreclose circuit-breaker lcd display, segment module with blue led
- charger negative character lcd display,white led ,battery segment small flexible display
- character small charger lcd display ,custom battery display ,white led
- segment positive temperature time clock lcd display,blue TN white backlight
Product Details
Place of Origin: | Guangdong, China | Brand Name: | CDTech | Model Number: | S035V01 tft lcd module |
Type: | TFT |
Product Description
Gneral specifications
Characteristics | Size | 3.5inch |
Resolution | 480(horizontal)*640(Vertical) | |
Interface | 18bit-RGB+3-SPI/MCU | |
Connect type | Connector | |
Color Depth | 18 bit | |
Technology type | a-Si | |
Display Spec. Pixel pitch (mm) | 0.111 x 0.111 | |
Display colors | 262K | |
Pixel Configuration | R.G.B. Vertical Stripe | |
Display Mode | Normally White | |
Driver IC | HX8363-A | |
Surface Treatment | HC | |
Viewing Direction | 9 O’clock | |
Mechanical | LCM (W x H x D) (mm) | 64(H)*85(V)*2.9(T) |
Active Area(mm) | 53.28(H) x 71.04(V) | |
With /Without TSP | Without TSP | |
Weight (g) | TBD | |
LED Numbers | 8 LEDs |
Drawing for High quality 3.5 inch TFT LCD Module display
Packaging Details: Carton size:385X155X227 mm ,300 pcs one carton
Delivery Time:3-5 weeks
