Help CenterCheap Small 700tvl Sony Effio-e 960h Ccd CVBS Output Analog 2.8-12mm Dome Cctv Camera
Related Products
-
High Definition Camera SONY EFFIO-V 800TVL Super WDR Defog 3NDR 2.8-12MM Manual Zoom Lens IR Dome CCTV Camera Vision StarUS$ 29.5 - 42.5MOQ: 1 Piece -
Vandalproof 800tvl IR Dome CCTV Camera 36Pcs Leds Sony Effio-V CXD4141GG With 2.8-12MM Manual Zoom Lens Indoor Using Vision StarUS$ 22.3 - 75.3MOQ: 1 Piece
-
IR Dome CCTV Camera 30Pcs Leds Sony Effio-V CXD4141GG Vandalproof 800tvl With 2.8-12MM Manual Zoom Lens Vision StarUS$ 29.5 - 82.5MOQ: 1 Piece
-
Camera Sony 36Pcs IR Leds OSD Menu 2.8-12MM Manual Zoom Lens Super WDR Sony Effio-V 800TVL Home Camera Vision StarUS$ 22.3 - 75.3MOQ: 1 Piece
-
High Performance Plastic Indoor Dome Camera With 2.8-12mm Manual Zoom Lens Osd Menu Sony Effio-V ir Camera 800TVL Vision StarUS$ 25.7 - 48.7MOQ: 1 Piece
1/3" Sony ccd 700tvl 2.8-12mm lens OSD menu analog BNC connector dome cctv camera
1/3" SONY CCD, Effio-e 700TVL
SONY Super HAD CCD II (ICX810/1AKA)
22pcs F5 IR-LED, IR Range more than 20M
OSD/2D-DNR/BLC/MD/Privacy Masking
3-Axis Design, easy for installation
2.8-12mm Lens, dome type for indoor / internal
Model No. |
VS-D3672IR |
Camera Type |
Color Weatherproof IR Camera |
Image Sensor |
1/3"SONY Super HAD CCD II |
Effective Pixels |
PAL:976(H) x 582(V)570K, NTSC:976(H) x 494(V)480K |
Signal System |
PAL /NTSC |
Horizontal Resolution |
700 TV Lines |
Min. Illumination |
0.01 LUX/F1.2 |
Lens Mount |
Varifocal 2.8-12mm Lens/F1.4 |
Iris Control |
Auto/Manual |
S/N |
≥52Db (AGC OFF) |
OSD Menu |
Support |
Language |
8 languages (EN, FR, DT, ES, POR, CN, RCN, RUS,JP) |
White Balance |
Push/User/Antic/Manual/Push lock/ATW |
Picture Adjust |
Mirror/Brightness/Contrast/Sharpness/HUE/Gain |
ATR |
Yes |
Motion Detection |
Yes |
Privacy Mask |
4 masks |
Day & Night |
Color / B/W / Auto |
Noise Reduction |
2D-NR |
HLC |
Yes |
AFD |
Yes |
SYNC |
Internal |
Shutter |
PAL:1/60(Sec.)~1/100,000(Sec.), NTSC: 1/50(Sec.)~1/100,000(Sec.) |
Infrared Luminary |
22 pieces IR-LED |
Infrared Wavelength |
850 nm |
Illuminate Distance |
More than 20 M |
Waterproof Criterion |
IP66 |
I/O Connector |
Power : DC Power Jack , Video Output : BNC |
Video Output Level |
1.0 Vp-p (75 Ohms, composite) |
Supplied Voltage |
DC12V Voltage |
Power Consumption |
IR On: 280mA max., IR Off: Less than 130mA |
Dimensions |
10o x 125mm |
Weight |
Approx. 0.4kg |
Vision Star is a real factory produce IP camera, Analog Camera, including bullet type, dome type, mini type, special type indoor & outoor cctv cameras. We always strive to offer customers high quality cameras with fast delivery, reasonble price, and good service. If you have any interest in our cameras, please let us know. We will reply you as soon as possible within 24 hours.
Competive price!!!
Two yeasrs Warranty!!!
High Quality!!!
Good service!!!
