Feature |
Spec |
|
Characteristics |
Size |
2.9 inch |
Resolution |
320(horizontal)*120(Vertical) |
|
Interface |
2. Serial Peripheral Interface (SPI) 3.18-/6-bit RGB interface(DEN, DOTCLK,HSYNC,VSYNC,DB[17:0]) 4. VSYNC interface (system interface + VSYNC) 5. WSYNC interface (system interface + WSYNC) |
|
Connect type |
Connector |
|
Color Depth |
262K |
|
Technology type |
a-Si |
|
Display Spec. Pixel pitch (mm) |
0.219 x 0.219 |
|
Pixel Configuration |
R.G.B. Vertical Stripe |
|
Display Mode |
Normally White |
|
Driver IC |
SSD2219 |
|
Surface Treatment |
HC |
|
Viewing Direction |
6 O’clock |
|
Mechanical |
LCM (W x H x D) (mm) |
76.90*37.72*3.2 |
Active Area(mm) |
70.08 x 26.28 |
|
With /Without TSP |
Without TSP |
|
Weight (g) |
TBD |
|
LED Numbers |
6 LEDs |
|
Drawing
Shipping : 3-5 weeks
1. Put module into tray cavity.
2. Tray stacking .
3. Put 1 cardboard under the tray stack and 1 cardboard above.
4. Fix the cardboard to the tray stack with adhesive tape.
5. Put the tray stack into carton.
6. Carton sealing with adhesive tape.
CDTech Electronics was established in 2009, is a hightech company who focus on the LCD R & D, manufacturing and selling. We can Provide professional, perfect lcd solutions to customers.
Our LCD products are widely applied to telecommunications, Medical area, industrial control area, consumer electronics, automotive electronics and many other fields. We have professional R & D team, who can develop, design and customize all kinds of LCD/LCM for customers, OEM and ODM are very welcome.
We can guarantee world advanced technology LCD/LCM manufacturing workshop, providing the high quality and efficient services and quick feedback. We have been establishing good relationship with Philips, Devilbiss, Midea Group, CHIGO Group, Harman Kardon, ABB, Micronet etc. Our main agents in France, Italy, Taiwan and other brand industrial LCD, size is from 1.77 ” to 42” . According to customers demand,we can also provide a variety of LCD panel accessories : LCD driving board, touch screen, inverter, HMI ,and so on.
Our aim is to assure the top quality and to serve our customers heart and soul. With the continuous competitiveness, it is our mutual goal to look for a path better in line with market rules!
Integrated Product Line
Our Workship
Q: 1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q: 2. What is the lead time for sample?
A: Current sample needs 1-3 days, customized sample needs 15-20 days.
Q: 3. Do you have any MOQ limit?
A: Our MOQ is 1PC.
Q: 4.How long is the warranty?
A:12 Months.
Q: 5. what express do you often use to send the samples?
A: We usually ship samples by DHL, UPS, FedEx or SF. It usually takes 3-5 days to arrive.
Q: 6. What's your acceptable payment term?
A: Our usually payment term is T/T. Others can be negotiated.
Q: 7. How to proceed the order if I have logo to print?
A: Firstly, we will prepare artwork for visual confirmation, and next we will produce a real sample for
your second confirmation. if sample is ok, finally we will go to mass production.
