Home > Consumer Electronics > Display & Accessories > LCD Module > TP02G-AS1 Delta Text Panel Small Industrial Text Display

TP02G-AS1 Delta Text Panel Small Industrial Text Display

Name: TP02G-AS1 Delta Text Panel Small Industrial Text Display
Brand: Delta
SKU: 112770693
Availability: InStock

TP02G-AS1 Delta Text Panel Small Industrial Text Display thumbnail-1

TP02G-AS1 Delta Text Panel Small Industrial Text Display photo-1

US$ 50 - 200 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Delta

Model Number:

TP02G-AS1

Contact Supplier Request Quote Chat Now

Fast To Buy Commerce (Shenzhen) Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/Hongkong/Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Delta

Model Number TP02G-AS1

Type STN

Welcome

Thanks for your visiting, for product details, competitive price or more items, welcome to contact Surina directly. :)

Product Description

TP02G-AS1 delta text panel small industrial text display

Only one programming cable is available, if you need communication cable, please inform us of your PLC model, We will provide the best service and quote the best price to you.
Configuration software: TPEditor V1.60 (free English versions)
Certification: UL US CE
TP Series Text Panel can communicate with most of the PLC, in especial
DELTA PLC, DELTA VFD Inverter, DELTA VFD-A/H Inverter, DELTA ASD AC Servo, DELTA VFD ASCII Mode, DELTA VFD RTU Mode, DELTA Modebus ASCII, DELTA Modebus RTU, FX Series, FX1N/FX2N Series, Modicon Modbus RTU Mode, Siemens S7-200 Series, FACON PLC FB-28MC, OMRON PLC Cseries, AB MicroLogix 1000, AB SLC-5 Series, YOKOGAWA ACE, LG_200S,TAIAN PLC, EATON PLC D50, VIGOR M Series, KOYO K-Sequence, GE Faunc PLC – VersaMax – SNPX, LG_K120S,DELTA Mx.
Features
The screen of this series can display two lines text or message at the same time. It not only has the features of light weight, cost-effective price, good flexibility in use, and easy-to-control operation, but also supports various communication protocols.

Specification

*STN LCD single color
*160*32 pixels
*256K Flash Memory
*16 multiple function keys
*Back-light auto turn off setting
*Power, Communication, Alarm LED
*2 Comm. Ports. It can communicate with different communication protocols simultaneously.
*Provide "program copy card" function: Save download time.
*Support multi-languages display
*CE & UL approved

Specifications	TP02G-AS1
Display	Monochromatic STN LCD
Effective Display Area	(W) x (H) = 72 x 22 (unit: mm)
Display Resolution	160×32: ASCII: 5×8, 8×8, 8×12, 8×16
LCD Contrast Adjustment	Set by Software, adjust the contrast by the press button in the function table
LCD Backlight Type	LED Backlight Automatic Turn-off Setting
Function / Numeric Keys	F0 / 0 ~ F9 / 9, ESC, ENTER and Arrow Keys
External Input Power	24V (3W Max.)
Memory Capacity	256K Byte
CPU	Hitachi HD64F3064F
RAM of System	32K Byte
Communication Interface	COM1: RS-232 COM2: RS-485
Waterproof Class of Front Panel	IP65 / NEMA4
Operating Temperature for Hardware	0 ~ 50°C; 20 ~ 90%RH (non-condensing)
Storage Temperature for Hardware	-20 ~ 60°C
Vibration	5Hz</=f<9Hz = Continuous:1.75mm / Occasional: 3.5mm 9Hz</=f<150Hz = Continuous:0.5g / Occasional: 1.0g
Shock	15g peak, 11ms duration, half-sine, three shocks in each direction per axis, on 3 mutually perpendicular axes (total of 18 shocks)
Radiated Emission	CISPR11, Class A
Electrostatic Discharge Immunity	EN61000-4-2
Radiated Immunity	EN61000-4-3
Electrical Fast Transient	EN61000-4-4
Weight / Dimensions	0.24kg; 147×97×35.5mm (Width(W) × Height(H) × Deep(D))
Cooling Method	Natural Air Cooling
