Semi-Automatic Pneumatic Filling Machine

Semi-Automatic Pneumatic Filling Machine thumbnail-1
Semi-Automatic Pneumatic Filling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Beverage, Medical, Chemical
Packaging Type:
Cans, Bottles
Contact Supplier Request Quote Chat Now
Wuhan Global Exchange Import And Export Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Food, Beverage, Medical, Chemical
Packaging Type Cans, Bottles
Packaging Material Plastic, Metal, Glass
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage AC 220V 50/60HZ
Power 380 Watt / Nozzle
Place of Origin China
Model Number C-811-GS-C-009
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

- Cover from non to high viscous liquid filling
- Flexible tube pump and piston types are available





Overveiw

 Semi-Automatic Pneumatic Filling Machine





Non-viscous Liquid

 Features



•     Suitable for normal liquids, non/low viscosity liquids.

•     Non-leakage design, the liquids only fill through the flexible tube without touch with the other components

•     Less operation cost concept, only consumable is flexible tube.

•     Easy-adjusting design for filling volume adjustment.

•     Easy-Clean characteristic, change the flexible tube to adapt the filling material changing.

•     Equipped with International brands of isolation valves, avoid drop leakage, accurate filling.

•     Assurance of key components’ quality by selecting of International reputable brands

•     Various control method of filing for semi-auto type.

•     Simple maintenance, non-seal sub-assembly design.



Semi-Automatic Pneumatic Filling Machine



Application



Issue

Application Description

Applicable Filling Materials

1)         Normal Liquids

2)         Not applicable for Paste

Particle Requirement

Applicable for Liquid or Fluid which consist of small size particle content

Corrosive Requirement

Applicable for Liquid or Fluid which consist of Corrosive and Poisonous content

Typical Filling Material

Liquids or Fluids like: Water , oil, Medicine, Chemical, Cosmetics and so on

Best Filling Range

10ml – 100ml



Specification



Catalogue 1A-xxx-xx

SLF-E1

SLF-E2

Control Method

Semi-Automatic Note 1

Semi-Automatic Note 1

Number of Filling Nozzles

1

2

Range of Filling

10-100ml/10-1000ml

10-100ml/10-1000ml

Filling Speed

>=10L/min

>=10L/min

Filling Tolerance

<= (+/-)1%

Compress Air Required

Not Applicable

Not Applicable

Air Consumption

Not Applicable

Not Applicable

Power Requirement

AC 220V 50/60HZ

AC 220V 50/60HZ

Electricity Consumption

380w

2*380w

Explosive-Proof

Optional Feature

Optional Feature

Approximate Weight ( Gross/Net)

23/18 kg

29/25 kg

Dimension ( ‘mm )

655*495*386mm

695*480*385mm







Viscous Liquid



Semi-Automatic Pneumatic Filling Machine



Catalogue 1A-xxx-x

SLF-P

Specific Type

P6

P12

P25

P50

P100

P250

P500

Special Apply for

Liquids with large range of viscosity , even with corrosive, flammable and explosive characteristics

Control Method

Semi-Automatic Note 1

Number of Filling Nozzles

1

1

1

1

1

1

1

Ideal Range of Filling-ml

25-60

50-120

100-250

200-500

400-1000

800-2500

2000-5000

Filling Speed -BPM

0-50

0-50

0-50

0-50

0-50

0-40

0-30

Filling Tolerance

<= (+/-)1%

Compress Air Required

4-6 bar

4-6 bar

4-6 bar

5-8 bar

5-8 bar

5-8 bar

5-8 bar

Power Requirement

Not Applicable

Electricity Consumption

Not Applicable

With Hopper

No Hopper

Approximate Weight -G/N

23/27

23/27

23/27

77/82

77/82

77/82

77/82

Dimension ( ‘mm )

785*425*530

862*412*530

918*420*480

1112*477*480

1175*505*480

1342*550*480

1264*634*480



Semi-Automatic Pneumatic Filling Machine



Catalogue 1A-xxx-x

SPF-P

Specific Type

P6

P12

P25

P50

P100

Special Apply for

Suitable for Paste filling , optionally with pre-heating requirement

Control Method

Semi-Automatic Note 1

Number of Filling Nozzles

1

1

1

1

1

Ideal Range of Filling-ml

25-60

50-125

100-250

200-500

400-100

Filling Speed -BPM

0-30

0-30

0-30

0-30

0-30

Filling Tolerance

<= (+/-)1-2%

Compress Air Required

4-6 bar

4-6 bar

5-8 bar

5-8 bar

5-8 bar

Power Requirement

AC 220V 50/60HZ

AC 220V 50/60HZ

AC 220V 50/60HZ

AC 220V 50/60HZ

AC 220V 50/60HZ

Electricity Consumption

10w

10w

10w

10w

10w

Approximate Weight -Net

21kg

23kg

30kg

35kg

45 kg

Dimension –Machine ( ‘mm )

850*360*360

920*360*360

1080*360*360

1160*410*410

1170*360*360

Dimension –Hoper ( ‘mm )

530*380*400

530*380*400

620*450*440

620*450*440

620*450*440

With Hopper

Yes

Yes

Yes

Yes

Yes

Hopper Volume - Liter

20-50

With Pre-Heating

No

No

No

No

No



Semi-Automatic Pneumatic Filling Machine



Catalogue 1A-xxx-x

SPF-P

Specific Type

P6

P12

P25

P50

P100

Special Apply for

Suitable for Paste filling , Equipped with pre-heating and stirring devices

Control Method

Semi-Automatic Note 1

Number of Filling Nozzles

1

1

1

1

1

Ideal Range of Filling-ml

25-60

50-125

100-250

200-500

400-100

Filling Speed -BPM

0-30

0-30

0-30

0-30

0-30

Filling Tolerance

<= (+/-)1-2%

Compress Air Required

4-6 bar

4-6 bar

5-8 bar

5-8 bar

5-8 bar

Power Requirement

AC 220V 50/60HZ

AC 220V 50/60HZ

AC 220V 50/60HZ

AC 220V 50/60HZ

AC 220V 50/60HZ

Electricity Consumption

3kw

3kw

3kw

3kw

3kw

With Hopper

Yes

Yes

Yes

Yes

Yes

Hopper Volume - Liter

20-50

With Pre-Heating

Yes

Yes

Yes

Yes

Yes

With Stirring Device

Yes

Yes

Yes

Yes

Yes





Documentation

Following documents are available, but not limited,  to be provided upon the stage of purchasing



No

Document

Code

Description

1

Products Selection Guide

SG

To select or customize the suitable products for the clients upon the feedback of Selection Guide, which include project background, parameters and other client’s requirement

2

Products Profile

PP

To enable the clients understand the overview of the products, Covers sections of Basic Features, Application, Construction, Typical Products, Approvals, and Optional Features

3

Installation Instruction

IN

To explain the step of installation of the equipment, and include commissioning instruction as well

4

User Manual

UM

To cover the content of Operation & Maintenance and Trouble Shooting





Our Services

Semi-Automatic Pneumatic Filling Machine





Customization

Customization Philosophy



The product demonstrating may not perfectly meet your requirements, our philosophy is to customize your real need, To minimizing idle capacity and function. To supply you performance and cost balanced products. Following are the factors shall be taken into account during customization:



  • Filling Materials
  • Container to be filled, type and specification.
  • Capacity requirement
  • Heating or stirring requirement before filling
  • Protection requirement
  • Other specific requirement



Selection Guide



Selection Guides are available for circulation, contact us to get products selection and customization support.



Semi-Automatic Pneumatic Filling Machine



Statement

  • The pictures demonstrating in this profile represent products of range, and subject to the newest or customized design
  • Due to the huge number of documentation updating, the data indicated in this profile may not be updated timely, Please contact with our customer service for newest version.
  • The features or functions appear in this profile subject to the additional description of quotation
