Help CenterLDK Concentric Locking Collar Ue208 Bearing
Related Products
-
LDK Concentric Locking Collar Bearing Ue206US$ 0.8 - 30MOQ: 200 Pieces -
LDK Brand Ball Bearing UE SeriesUS$ 0.8 - 30MOQ: 200 Pieces
-
NA208 Ball and Socket BearingUS$ 1.5 - 20MOQ: 500 Pieces
-
2013 Hot Spherical Ball Bearing InsertsUS$ 1.5 - 20MOQ: 300 Pieces
-
LDK SER205 Carbon Steel Ball BearingsUS$ 1.5 - 20MOQ: 500 Pieces
Specifications
1)Can be assembled into the various housings2)Material:Cast iron and stainless steel
3)Series:UE200,SUE00,UER200,SUER200
1.Details of LDK UE208 bearing
2.Special features
1) Material for chrome steel and stainless steel available
2)Low noise and high speed
3)Large load capacity
4)High quality and long life
5)OEM welcome
3.More details
LDK’s ACCU-GRIP Concentric locking Insert Bearings.Designed for a quieter ,smoother and more efficient running under high radial loads and a true center line.
True Centerline
The inner race closes down on the shaft from 360 degrees all sides creating a true centerline resulting in even and constant balance, thus results in better operation and longer life..
reduce noise and vaibration
The uniform grip of the inner race to the shafts results in lower noise and vibration levels at high speeds
Qucik and Easy Installation
One step installation - only a single standard hex head cap screw - in one position.
Shaft protection
The concentric locking significantly reduces the chance of marring or damaging the shaft thus significantly reduce fretting corrosion. Especially for stainless ACCU-GRIP series, due to this feature, it will significantly reduce bacteria and thus a better choice for food & beverage etc industry which requires high Hygeia requirement.
More efficient fan balancing
Because the ACCU-GRIP Ball Bearing is totally concentric with the shaft, it will not induce vibration into the fan/blower system and will reduce the fan OEM*s trim balancing time for high speed applications. No 1 choice for HVAC industry.
Reduced shafting costs
The ACCU-GRIP Ball Bearing only requires commercial grade shafting tolerances. This can save approximately 40% in shafting costs versus turned, ground and polished shafting.
UE SERIES INSERT BEARINGS ARE INTERCHANGEABLE WITH SETSCREW AND ECCENTRIC LOCKING COLLAR TYPE INSERTS.
| BEARING TYPE | LOCKING BY | DISADVANTAGE COMPARED TO UE TYPE |
| UC | SETSCREW | DAMAGE TO SHAFT,UN-UNIFORM LOCKING,NOT SUITABLE FOR HIGH SPEED ROTATION |
| NA | ECCENTRIC LOCKING COLLAR | NOT SUITABLE FOR HIGH SPEED AND REVERSE ROTATION |
| UK | ADAPTER SLEEVE | NEED TO SELECT A LARGER BORE SIZE BEARING AND NEED A SPANNER FOR FIXING. |
|
UE SERIES INSERT BEARINGS COULD BE USED WITH BERAING HOUSING MADE OF CAST IRON,PRESSED STEEL,ALL STAINLESS AND THERMOPLASTIC
| ||
4.Company Introduction
1) Enterprise group combines industry with International trade
2) The 13th Year's Gold Supplier in Alibaba
3) Strict quality controll system with perfect facilities
4) Advanced production facilities
5) The abundant capability of R&D
6) High&New Tech enterprise,low carbon omission and environment friendly
LDK office building & workshop & warehouse
LDK part of production & quality controll equipments
5. For more details of our products,please visit:
