XSCM CE 4wd Zl-10 Electric Mini Wheel Loader
US$ 9,000 - 12,800
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
XSCM electric mini wheel loader
Model Number:
zl-10 electric mini wheel loader
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XSCM ST953 CE Approved 5 Ton Chinese Wheel LoaderUS$ 9,000 - 60,500MOQ: 1 Set -
XSCM ST920T ce 4wd Zl18 Wheel Loader MachineUS$ 9,000 - 60,500MOQ: 1 Set
-
XSCM ST938 3.5 Ton ce Articulated Wheel LoaderUS$ 30,500 - 38,500MOQ: 1 Set
-
XSCM Zl50g ce Powerplus Wheel LoaderUS$ 43,700 - 44,200MOQ: 1 Set
-
XSCM ce Approval High Quality 3 Ton Wheel LoaderUS$ 9,000 - 60,500MOQ: 1 Set
Condition
New
Brand Name
XSCM electric mini wheel loader
Model Number
zl-10 electric mini wheel loader
Place of Origin
China
Type
Mini Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
4750*1650*2720mm
Rated Load
1000kg
Certification
CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
XSCM ce 4wd zl-10 electric mini wheel loader with 0.5CBM bucket,flexible operation,good visibilityXSCM CE 4wd zl-10 electric mini wheel loader use China Changchai 490 engine with low oil consumption, rational power distribution and excellent cooling system
ZL-10 electric mini wheel loader automatic bucket flat, over load protection system,adjustable wheel,wireless radio,far and near flash lamp
the ce 4wd ZL-10 electric mini wheel loader main specifications as following:
| Rated load | 1000kg |
| Rated bucket capacity | 0.5m3 |
| Bucket width | 1600mm |
| Tread | 1400mm |
| Wheel base | 1580mm |
| Min. turning radius | 3890mm |
| Min. ground clearance | 230mm |
| Max. dumping height | 2200mm |
| Dumping reach | 850mm |
| Lifting time | 4s |
| Hydraulic cycle time | 9s |
| Max. tilt angle | 30° |
| Breakout force | 26KN |
| Driving mode | Four-wheel drive |
| Operating weight | 3300kg |
| Dimension(L*W*H) | 4750*1650*2720mm |
| Engine model | Changchai 490 |
| Start mode | Electric |
| Rated power | 29KW |
