Multi-Function Electric Hospital Bed With LCD Display

Detail Information of  Electric Hospital Bed

SPECIFICATIONS:

   1. MATERIAL:     Steel framework, ABS & PP for plastic part

   2. DIMENSION:     L2330×W1050×H530-710mm

   3. BED BOARD:     L1955×W900mm

   4. NET WEIGHT:   158kg     LOAD CAPACITY: <250kg

   5. Five functions with 4 Denmark motors

FEATURES:

• Five big functions, containing 4 Danish motor, equipped with advanced touch switch , to solve the finite lifetime and capacity of traditional mechanical key the key failure problem.
• The head of a bed side about two fence equipped with embedded touch keyboard , make the patient free adjustment of the bed body posture. The end of the bed plate on 10.2 inch touch screen control system shows the bed body attitude data in real time, can be used for the medical personnel to the gesture operation on the bed body, and the system can be locked to ensure safety.
• Back angle (0-65 degrees), knee angle (0-43 degrees), a height adjustment(710mm-530mm), tilt (10 degrees) and anti tilt (10 degrees), the bed body posture are realized by the electric operation, equipped with lights, to display the function execution status.
• The bed body can be various attitude data storage, and the bed body posture calls saved to quickly reach the required attitude.
• With weighing function, and can be on the weight of data storage. At the same time, the medical staff can range setting allows the weight change, the graph shows the change of the weight, overrun alarm system generated after.
• From the bed, with alarm function.
• A key to show flat key, can make the bed body quickly back to its initial state at any angle.
• Equipped with a battery, to respond to emergency situations such as power failure.
• The bed panel with soft connection, position change the bed body, a bed panelis natural radian, will make the patients feel uncomfortable.
• In the control wheel system, through the foot control bed tail beneath the imple mentation of release the brake and brake.
• Bed four angular distribution of saline shelf holes, easy to use.
• Rail for the luxury European style ABS guardrail, around two group, using the damper can make down buffer folding; color matching and the bed tail plate ,make the bed design more unity.
• The head tail board of symmetrical type socket can be quickly disassembled, meet the clinical emergency needs, bed end set outside the patient information socket.

LCD Display

Q1. How will my products be shipped?
A1. By the most expedient and cost-effective method available.

Q2.Can I use our brand on the products ?
A2. Yes

Q3: How can I install my furniture?

A3: After shipped the goods,we will send you the detailed furniture installation drawing .If still can’t solve ,we can arrange our engineer to your country for anwhile we will send you the assembly accessory for free

Q4: Is assembled package or unassembled package?

A4: it’s unassembled package.

Q5: What can I do if I received the broken products?

A5: First take a photo and send to us ,after we check and confirm is our products’ problem,we will send the products for free.

Q6. What if I have questions?
A6. Call us at 86-20-39283092, or email at mei.yip#  (note:#=@).We'll be happy to help.
