High speed embroidery machine :
1)take dahao 10 inch touch screen computer , model of C88.
2)main motor and XY both take dahao servo motor.
3)head system with double cam with motor jump (LH) . normally machine is single cam with solenoid jump . and even if the single cam also devide two kinds , but the double cam special for high speed running .
4)double cam motor jump need use the special high speed cards . it only high speed machine have . that can let the flat working 1000-1200rpm . sequin machine running 900rpm .
5)high speed machine body , because it need always high speed running , so it must need reduce its vibration during working , so we have one kind special for high speed running body , 400x400x12mm beam much heavy body .
6)color change use the linear system , normally machine use bearing system .
7)high speed special Jap rotary hook , it different with normal speed Jap hook .
8)high speed running always need add oil, so machine install the auto oil system
9)top tension also use special for high speed running , it can pass the thread more fluently , much reduce thread cut problem
10)sequin device single or double available .
11)one ctn free accessories for each set machine
12)every set machine have one year free after service , give tech supply free .
Notice:
We are manufacturer of embroidery machine in zhuji city of china.
We have 10 years experience to specilize in computerized embroidery machine.
Our company name is Zhuji Jindao Mechanical & Electrical Co.,Ltd.
Before name is Zhuji Mingdao Mechanical & Electrical Manufacturing Co.,Ltd for 8 years.
Standard configuration:
- Auto color changing and auto trimmer
- Computer: Dahao computer 5inch LCD with usb port (8"LCD or 10"LCD is available)
- Main Motor: Toshiba induction motor, X. Y stepping motor
- Original imported rotary hook.
- Original imported German continental time belt
- Original imported NSK bearings for main driving units
- Speed: 250-1000rpm
- Our standard accessories
Above are recommended configures only, the real production configures shall be final.Since we always improve our machines.
Advanced Features:
- Machine head linear rail.
- 80mm wide machien head box.
- Hanging type wide needle bar case
- Excellent quality of tatami embroidery.
- Total solutions for special thick fabric embroidery, special thin fabric embroidery,
