10kv Termination Kits (outdoor Type) for 3 Cores 25~50 Mm2 XLPE Insulated Copper Cable

Name: 10kv Termination Kits (outdoor Type) for 3 Cores 25~50 Mm2 XLPE Insulated Copper Cable
Brand: CONNECT
SKU: 112724275

US$ 1 - 100 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

CONNECT

Model Number:

CN-WRS-8.7/15-1

Connect Cable Accessories Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name CONNECT

Model Number CN-WRS-8.7/15-1

Specifications

1.light weight
2.install convenient
3.stable property, reliable operation
4.waterproof

1. Guaranteed technical particulars for 11kv terminations kits (outdoor type) for 11kv 3*185mm2 XLPE insulated copper cable

SL.NO	DESCRIPTION	PURCHASE’S REQUIREMENT	MANUFACTURER’S PARTICULARS
1	NAME OF THE ITEM	TERMINATION KITS (OUTDOOR TYPE) FOR 11KV 3*185MM2, XLPE INSULATED COPPER CABLE	Termination kits outdoor type for 11kv 3*185mm2 XLPE insulated copper cable
2	MANUFACTURER’S NAME& ADDRESS	TO BE MENTIONED	Jiangsu connect high voltage cable accessory co,ltd
3	MANUFACTURER’S MODEL NO.	TO BE MENTIONED	CN-WRS-8.7/15-2
4	STANDARD	PERFORMANCE, DESIGN AND TESTING SHALL BE IN ACCORDANCE WITH THE BS, IEC, VDE OR EQUIVALENT INTERNATIONAL STANDARDS.	IEC60502, GB/T12706
5	ALLPICATION	FOR 11KV 3*185MM2, XLPE INSULATED COPPER CABLE WITH ARMOUR	For 11kv 3*185mm2, XLPE insulated copper cable with armour
6	INSTALLATION	OUTDOOR, TO BE INSTALLED ON POLES/STRUCTURE	Outdoor, to be installed on poles/structure
7	NOMINAL SYSTEM VOLTAGE	11KV (PHASE TO PHASE)	11kv
8	MAXIMUM SYSTEM VOLTAGE	12KV (PHASE TO PHASE)	12kv
9	NUMBER OF CORES	3	3
10	SIZE OF THE CONDUCTOR	185MM2	185mm2
11	TYPE OF INSULATION	XLPE	XLPE
12	TYPE OF SCREENING	COPPER TAPE/COPPER WIRE	Copper tape/copper wire
13	TYPE OF CABLE BOX	AIR FILLED	Air filled
14	SYSTEM NEUTRAL EARTHING	EFFECTIVELY EARTHED	Effectively earthed
15	MINIMUM PERFORMANCE DATE FOR AC VOLTAGE WITHSTAND, IMPULSE VOLTAGE WITHSTAND AND DC VOLTAGE WITHSTAND	To be mentioned	49.5kv/5min

Kit Components
