2016 hot sale 110kV prefabricated straight through joint
- 50 Set / Sets per Month
- Shanghai
- T/T
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | CONNECT | Model Number: | CN-YJJTZ/CN-YJJJZ |
Type: | Other, TERMINATION KIT |
Product Description
Product Introduction
Our company produces CN-YJJTZ assembly straight through joint and CN-YJJJZ insulating joint two type products applied to any cross section. Both of them are used to connect any cross section between two cables.
Products are composed of epoxy insulation body (epoxy bushing), stress cone, cone prop, and wiping sleeve. If necessary, fiberglass protective shell can be added.
Main body of epoxy insulating adopts epoxy resin vacuum pouring forming. Stress cone adopts imported liquid silicone rubber pouring forming. Cone prop tight top of stress cone with long-term stability of the hold force and uniform electric field capacity. Outer Protective shell with waterproof sealant inside protects from water corrosion, which is optional to customers. The products use multiple sealing structures to prevent the intrusion of moisture. All of the seal rings are composed of imported NBR or silicon rubber. All of the fasteners are composed of stainless steel with good waterproof performance.
The cross sectional areas range of cables with supporting accessories of various voltages is as following:
48/66kV-56/77kV 150-1400mm²
64/110kV-7-290/500kV 400-3000mm²
Product Characteristics:
1. Wide application: It can connect any cross section between two cables, which prefabricated rubber insulated joints cannot be achieved.
2. Any conversion of straight-through and insulated joint, which prefabricated rubber insulated joints cannot achieve.
3. Easy installation: the length of processing cable for plug-in structure termination is less than 300mm. The dry-type structure is oil free and gas free, greatly reducing the labor of installation.
SIZE | TYPE | 66kV | 77kV | 110kV | 138kV | 220kV | 500kV |
L | CN-YJJTI | 680 | 720 | 868 | 960 | ||
CN-YJJJI | |||||||
A | CN-YJJTI | 2300 | 2400 | 2600 | 2800 | ||
CN-YJJJI | |||||||
B | CN-YJJTI | 1650 | 1700 | 1900 | 2100 | ||
CN-YJJJI | |||||||
SIZE | TYPE | 66kV | 77kV | 110kV | 138kV | 220kV | 500kV |
L | CN-YJJTI | 680 | 720 | 868 | 960 | ||
CN-YJJJI | |||||||
A | CN-YJJTI | 2300 | 2400 | 2600 | 2800 | ||
CN-YJJJI | |||||||
B | CN-YJJTI | 1650 | 1700 | 1900 | 2100 | ||
CN-YJJJI |
We also have the following products:
Typical Drawings for connectors/terminatals/terminations:
Other Products produced by us.
Workshops and Largest Testing Center in China in line of Cable Accessory
CONNECT Service:
Hi, I am Cecilia Zhang
I'm glad to serve you.
Now I want to list some information that I think you will be more interested in.
Want to get more info about our products and company? You can scan our home page () and click my link.
SKYPE:cecilia13148
QQ:1326235138
Thank you!
Why choose us?
Export to many countries including Australia, New Zealand, UK and USA.
Best manufacturing and testing equipments imported from Germany, USA and Japan guarantee the best quality with competitive prices.
Professional overseas team guarantees you best pre-and-after sale services.
Experienced engineers and workers for more than 20 years ensure the quality and customized products.
5S Management to enhance the qualifications of staff and make better service for customers.
Near Shanghai and Ningbo Port workshop makes it convenient to delivery on time.
Produts Testing Certificates
The main products cover all series of 1kV~35kV LV&MV cold and heat shrinkable cable accessories;66kV~500kV high& ultra-high voltage cable accessories which include porcelain bushing cable terminal ,composite bushing ,all prefabricated soft Silicone Rubber Dry Outdoor Terminal ,Rigid dry outdoor terminal, pluggable dry GIS terminal, straight joints, insulating joints, fully insulating and sealing dry Y Type branch joints, conversion joints, inter-connected boxes, grounding boxes, and other support equipments. Copper, aluminum, copper and aluminum transitional devices of 16 ~2500mm2;cable clamps; devices for peeling and straightening cables; cable conveyors for 300~800kg,pay-off stand , devices for pulling and moving; rubber insulating tapes,semi-conductive tapes, waterproof tapes,etc.On specific customer demand ,a full range of cable design services are provided.
