Hdpe Liner Welding Machine

Specifications

 product description

1.Geomembrane welding machine can weld geomembrane of various thickness and are applicable for welding of all thermal-fused material such as LDPE, PVC, HDPE, EVA, PP and the like.

2.The control of this series of welding machine adopts automatic thermostatic control with high control accuracy and low temperature fluctuation;

3.Speed control adopts automatic voltage and speed regulation circuit, with great output torque and the operating is stable.

4.It can maintain a constant speed on the condition of creeping, vertical creeping and variable road load. Also this series of welding machine is stable in performance despite of external temperature and voltage variation.

5.This series of welding machine is excellent in performance and easy for operating, with high welding speed and good work quality. It is extensively used in engineering projects such as expressways, tunnels, reservoirs, waterproof of construction and so on

Voltage (V): 220V
Frequency (Hz): 50Hz
Power (P): 1800W
Welding speed (V): 0.5-5m/min
Heating temperature (T): 0-450°C
Thickness of material to be welded: 1mm-3mm
Overlap width: 120mm
Welding width: 14mm×2, interior cavity 16mm
Seam strength: ≥85% base material (tensile resistant in shear direction), complete machine
Weight: 13Kg

.

  application

Application covers refuse landfill anti-seepage project, sewage disposal anti-seepage project,

lake anti-seepage project, water conservancy anti-seepage project, tunnel anti-seepage project,

minerals place anti-seepage project, cultivation pond anti-seepage project, roofing waterproofing

 project etc.

our office

  company information
