Help CenterSingle Circuit Flexible Flat Switch Panel
Related Products
Specifications
flexible flat switch panel:low cost,long life,moisture-proof,dust-proof,waterproof,anti-oil,anti-corrosion,arbitrary designKey Specifications/Special Features:
Material: matte PC (smooth), gloss PC + matte oil, gloss PC, PET, and PVC
Thickness: 0.05---1.0mm
LED windows: transparent and translucent
Embossed keys: no embossed keys and domes, domes without embossed keys, embossed keys without domes, embossed keys and domes
Adhesive: 3M9448,3M9080,3M467,3M468, and no adhesive
Tail: tail with clear mask or green mask
Specialize in manufactuing membrane switch:
Overlay+circuit+LED+metal dome or poly dome array+connector+double side tape
EL backlight+Rubber keys
Aluminum plate+Rubber keys
Metal domes
Flat without Tactile Effect
Embossing with Tactile Effect
Embossing with Metal Dome
Membrane switch with FPC
Single circuit flexible flat switch panel
Performance indicators:
1. Electronic characteristics
Circuit rating: 35V (DC), 100mA, 1W
Contact resistance: 10Ω--500Ω (According the trace length and materials to comfirm)
Insulation resistance:> 100MΩ 250V DC
Contact bounce: ≤ 5ms Dielectric withstand:250VRms (50-60Hz 1min)
Life expectancy: flat type ≥ 500 million times, tactile type: ≥ 100 million times
2. Mechanical Properties Actuation force:flat type 57-284g (2-10 Oz), tactile type 170-397g (6-14 Oz) Switch stroke: flat type 0.1-0.5mm, tactile type 0.6-1.5mm
3. Environmental parameters
Operating Temperature: -40 - +80 , Storage temperature: -40 - +85
Humidity: 40 , 90% -95%, 240 hours
