Help CenterCustom Silkscreened Graphic Overlays in Any Size and Shape
Related Products
-
PET Menbrane Switch Used in Textile MachineryUS$ 1 - 10MOQ: 500 Pieces -
Tactile Plastic Remote Control PanelNegotiableMOQ: 1
-
Burglary Alarm Master PanelNegotiableMOQ: 500 Pieces
-
Custom Flate Type Graphic Overlay With LED BacklightUS$ 1 - 3MOQ: 500 Pieces
-
Membrane Switch Panel With FPCUS$ 1 - 5MOQ: 500 Pieces
Specifications
1.custom graphic overlay2.ISO9001:2008
3.durable 3M adhensive
4.100% QC
5.OEM&ODM welcome
Welcome customers to inquiry, we will try our best to meet your requirments.
Graphic Overlays
Graphic overlays offer a way to print your details/design onto scratch resistant label produced to your shape with the options of buttons, clear panels and openings. This allows the use of LED lights, digital displays or other information/objects to show/protrude through the label.
Specifications-Graphic Overlays:
Material-------------PET advised, matte PC (smooth), gloss PC + matte oil, gloss PC and PVC
Color---------------Pantone and RAL color matching system
Thickness------------0.4---1.4mm
LED windows--------transparent and translucent
Embossed keys-------no embossed keys and domes
------domes without embossed keys
-------embossed keys without domes
-------embossed keys and domes
Adhesive----------------3M9448,3M300LSE,3M467,3M468, Nitto etc.
Notes:All trademarks shown here are for reference purposes only. They are the property of their respective owners and we are not authorized to sell items bearing such trademarks.
Graphic overlay Performance Index------------ | |
1.Electronic characteristics | |
Circuit rating |
35V (DC), 100mA, 1W |
Contact resistance |
10Ω~500Ω (According the trace length and materials) |
Insulation resistance |
> 100MΩ 250V DC |
Contact bounce |
≤ 5ms |
Dielectric withstand |
250VRms (50~60Hz 1min) |
Life expectancy |
flat type ≥ 5 million times, tactile type ≥ 1 million times |
2.Mechanical Properties | |
Actuation force |
flat type: 57-284g (2-10 Oz), tactile type: 170~397g (6~14 Oz) |
Switch stroke |
flat type: 0.1~0.5mm, tactile type: 0.6~1.5mm |
3.Environmental parameters | |
Operating Temperature |
-40°C~+80°C |
Storage temperature |
-40°C~+85°C |
Humidity |
40°C, 90% ~95%, 240 hours |
