Specifications
Membrane keypad1.life:5 million times with LED
2.Humidity40C 90%-95% 240hours
3.100% function test
4.OEM&ODM services
At Lunfeng Factory
We provide superior quality membrane switches in a wide variety of
formats. In addition, we offer design engineering to ensure that
your membrane switches, front panels and graphic overlays
deliver excellence in function, durability and design.
Custom Membrane keypad with LED
Specification
|
Item |
membrane switch, keypad, membrane keypad, keyboard switch, switch panel, membrane panel, membrane overlay, membrane faceplate for variety electronic industries. |
|
Material |
Available in Polyester (PET) or Polycarbonate (PC). In experience we are suggest that PET is the best choice. |
|
Feature |
1. Maximum circuit rating——35V DC, 100mA, 1W |
Surface |
Gloss & smooth, velvet, matte & coarse finish, semi-gloss with semi-laminate. |
Embossing |
Dome above the circuit layer, it can be metal(stainless steel) dome |
|
Circuit layer
|
Available with LEDs in a variety of colors and standard male/ female connectors |
Adhesive |
Many brand for your choice. |
Actuation force |
1. Flat type 60 - 300g (2 - 10oz) |
Switch stroke |
1. Flat type 0.1 - 0.5mm |
Life expectancy |
1. Flat type——5,000,000 closures or more |
Surface hardness |
3H or more |
Operating temperature |
-40°C ~ +80°C |
Humidity |
90% - 95% (40°C) for 240hrs |
Thickness |
between 0.9mm-2mm |
Lead Time |
10 business days after prepaid. |
Sample |
Price: according to buyers’ designs. Time: 7 business days, can asap. |
Payment |
L/C, T/T, Western Union, paypal The other specific issues can be negociated. |
|
Advantages |
1.Over 15 years experiences. 2.Availabel in custom designs and OEM service. 3. We have professional printing equipments and skilled workers which can ensure the quality of the products. |
Custom-made membrane switch/membrane keypad Main Application:
Home appliances: washing machine, induction, microwave oven, remote control etc.
Industrial equipment: CNC lathe, injection molding machine etc.
Commercial equipment: cash register, electronic scale, refueling machine, medical equipment. Measuring instruments, telecommunication equipment, OA equipment, Information application productstoys…etc.
Notes:
All product, pictures and trademarks and shown here are for reference purposes only. They are property of their respective owners and we are not authorized to sell items bearing such trademarks.
Please feel free to contact us for any queries!
